04 19 Quality Products for Mechanical & Fluid Power SCREW PUMPS Marine Applications

an excellence in engineering The comprehensive service for the mechanical power transmission & fluid power industries. STRIPPING: Twin-screw pumps with and without drive gears for filling and emptying tanks for various types of fluids of various compositions. Great availability of flow rates. CARGO: Pumps for filling Terminal Silos, the tanks of ships equipped for transporting fluids, in addition to the main storage tanks for propulsion fuel fluids. Low-pressure medium and high flow rates with a vast range of treatable fluids and viscosities. TRANSFER: Fluid transfer systems from main tanks to daily tanks. Low-pressure medium and high flow rates with a vast range of treatable fluids and viscosities. SEPARATOR: Pumps, double booster systems and flow meter systems developed for use with low viscosity fluids with low sulphur content, in keeping with environment and emissions standards, designed to be long-lasting with reduced maintenance costs. The entire range is implemented with assembled motor - pump units with MAGNETIC DRIVE. FEEDER: Pumps, double booster systems and flow meter systems developed for use with low viscosity fluids with low sulphur content, in keeping with environment and emissions standards, designed to be long-lasting with reduced maintenance costs. The entire range is implemented with assembled motor - pump units with MAGNETIC DRIVE. BOILER/BURNER: Pumps and double booster systems for low viscosity, low and medium pressure fuel fluids, for boilers and burners. LUBE: 40 years of experience and success in fluid power, lubrication systems, including adverse environmental conditions in addition to temperatures and viscosities. A broad range of pumps are available for any plant engineering requirement. HYDRAULIC: High efficiency and stability for medium pressure up to 120 bar, for the following types of hydraulic systems: Propeller and Steering Gear. Screw Pump Applications This catalogue has a marine bias at present with industrial, and oil & gas to follow in the near future. Many of these screw pump models serve industrial, oil & gas and marine applications. Please check periodically for updates that include industrial and oil & gas sectors, as well as further models not currently listed. 01737 767493 info@jbj.co.uk www.jbj.co.uk - registered in England No: 1185469 - jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/E requirements You Tube jbj Techniques is a specialist manufacturer and distributor of high quality products for the mechanical power transmission & fluid power sectors.

Page Application Pump Types ................................................................... 1 - 2 PB Series ........................................................................................................ 3 - 4 PHS Series ..................................................................................................... 5 - 6 PZ Series ......................................................................................................... 7 - 9 PZD Series ..................................................................................................... 10 - 11 PXF Series ..................................................................................................... 12 - 14 PO - PWO Series ...................................................................................... 15 - 16 POF - PWOF Series ................................................................................ 17 - 18 2SP LS Series ............................................................................................. 19 - 20 2SP Series ...................................................................................................... 21 - 24 MPV2 Series ................................................................................................. 25 - 26 PDP Series ..................................................................................................... 27 - 28 SPB Series ..................................................................................................... 29 - 30 Magnetic Coupling Drive .................................................................. 31 Product Range Performance Chart ......................................... 32 SCREW PUMPS Screw Pumps Contents The details contained within this catalogue are reproduced in accordance with the latest information at publication of this catalogue. Errors & Omissions Excepted Last update: 24/04/2019

COMPONENT TYPE Three Screw Pumps Low Pressure COMPONENT MODEL 3 Flow Rate Up To M /h (lpm) Max Operating Pressure (bar) Typical Viscosity (Cst) Max Operating Temperature (°C) Stripping Cargo Transfer Separator Feeder Circulating Boiler / Burner Lube: Diesel Engine, Thruster, Gear Box Hydraulic * Fuel Oil: HFO- LFO- MGO-DO- LSMGO Mineral Oil / Lube Oil Body Materials Screw Set Materials Mechanical Seal Magnetic Coupling Integrated Relief Valve Standard In / Out Port Connection *Deck Machinery, Pitch Propeller, Steering Gear, Door and Ramp. **Depends from valve model and size. *** Up to size 083: SAE 3.000psi port / from size 1.2 - 5.000 1.2 - 5.000 1.2 - 5.000 1.6 - 5.000 10 - 5.000 10 - 5.000 1 - 15 16 16 16 16 30 120 40 150 150 150 120 120 120 120 2.5 (41) 12 (200) 288 (4.800) 600 (10.000) 288 (4.800) 34 (560) 34 (560) PB PHS PZ PZD PXF POF - PWOF PO - PWO Three Screw Pumps Medium Pressure GGG40 GGG40 GGG40 GGG40 GG25 C.S. GG25 GGG40 GG25 Nitrided Steel Nitrided Steel Nitrided Steel Nitrided Steel Carbon Steel Nitrided Steel Nitrided Steel Al SAE 3,000psi SAE 3,000psi SAE 3,000psi DIN***PN16 DIN PN16 DIN PN16 ANSI option ANSI option SAE 3,000psi Special Typical Applications Typical Fluids Main Characteristics Screw Pumps Application Pump Types SCREW PUMPS 1 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

0.7 - 5.000 0.7 - 5.000 1.2 - 5.000 1.2 - 5.000 1 - 5.000 10 - 5.000** 16/40 16/40 16 16/40 40/200 150** 300 300 150 150 150 100 600 (10.000) 1200 (20.000) 12 (200) 2.5 (41) 420 (7.000) 72 (1.200)** Nitrided Steel Nitrided Steel Nitrided Steel Nitrided Steel Nitrided Steel GGG40 C.S. GGG40 C.S. GGG40 C.S. GGG40 GGG40 GG25 N.A. N.A. N.A. N.A. N.A. N.A. SAE 3,000psi SAE 3,000psi DN PN DN32 PN16/40 1½” ANSI 150 DIN DIN ANSI option ANSI option option option SCREW PUMPS Screw Pumps Application Pump Types 2 - e 083 to 156: DIN flange. 2SP LS 2SP PDP SPB MPV2 VMP/BVPA Twin Screw Pumps Low Pressure Double Station Low Pressure Consumption & Control www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PB Series Technical Specifications 3 Allowable delivery pressure (continuous) up to 16 bar from 1000 to 3600 rpm (viscosity < 10 cSt) or up to 40 bar (> 10 cSt) Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Transfer, fuel supply, lubricating, boiler. Operating Data Handled fluid Fuel oil HFO - DO - LSMG0 - Hydraulic and Lube oils. Viscosity range From 1,2 to 5000 cSt. Pump speed From 750 to 3600 rpm * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 41 LPM - 2,5 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 40 bar (from 1000 to 3600 rpm). Operating temperature range From 0 to 150 °C * Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Lubricated for life. Mounting arrangement Horizontal or vertical mounting. Inlet & Outlet connection Special version. Materials Casing/Flanges Modular cast Iron GGG40. Screws Nitrided steel. O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk For hydraulic oils, lubricating oils. Special version for heavy fuel. www.jbj.co.uk/screwpumps.html #DriveLineHarmony

E F Ød2 D N O G Ød3 Ød4 I1 I2 d1 K shaft detail J M C B H A L P SCREW PUMPS Screw Pumps PB Series Technical Specifications 4 Dimensions in mm unless otherwise stated. Model A B C D E F G H I1 I2 J K L M N O P d1 d2 d3 d4 SAE SAE Gas Gas Ø Ø Ø Ø 3000 3000 PB020-025 318 65 67 29 16 5 45 151 115 111 16 5 1" 1" 1/8" 1/8" 93 14 100 11 125 in out www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PHS Series Technical Specifications 5 Allowable delivery pressure (continuous) up to 16 bar from 1000 to 3600 rpm Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Separator, transfer, booster, feeder, fuel supply, lubricating. Operating Data Handled fluid Fuel oil HFO - DO - LSMG0 - Hydraulic and Lube oils. Viscosity range From 1,2 to 5000 cSt. Pump speed From 750 to 3600 rpm * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 200 LPM - 12 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 16 bar (from 1000 to 3600 rpm). Operating temperature range From 0 to 150 °C * Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Lubricated for life. Mounting arrangement Horizontal or vertical mounting. Inlet & Outlet connection Special version. Materials Casing/Flanges Modular cast Iron GGG40. Screws Nitrided steel. O-rings Viton ®. Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk For hydraulic oils, lubricating oils. Special version for heavy fuel. www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PHS Series Technical Specifications 6 Model A B C D E F EF G H L M T V d1 d2 d3 d6 l1 l2 l12 l O1 O2 O12 O Ø Ø Ø Ø Ø Ø Ø Ø Ø PHS025 274 60 50 29 61.5 63.6 9 1/8" 73 60 68 16 5 14 110 130 9 62 28 9 25 62 28 9 25 PHS032 288 68 50 29 61.5 63.6 9 1/8" 73 75 68 16 5 14 110 130 9 90 40 11 40 62 28 9 25 PHS040 297 75 50 34 61.5 72 9 1/8" 83 85 75 21.5 6 19 120 145 11 90 40 11 40 90 40 11 40 in out Dimensions in mm unless otherwise stated. shaft detail www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PZ Series Technical Specifications 7 For hydraulic oils, lubricating oils. Special version for heavy fuel. Allowable delivery pressure (continuous) up to 16 bar from 1000 to 3600 rpm (vertical arrangement) Allowable delivery pressure (continuous) up to 16 bar from 750 to 1800 rpm (horizontal arrangement) Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Cargo, separator, Transfer, Booster, Feeder, Fuel supply, Lubricating. Operating Data Handled fluid Fuel oil HFO - DO - LSMG0 - Hydraulic and Lube oils. Viscosity range From 1,2 to 5000 cSt (specific configuration may apply). Pump speed From 750 to 3600 rpm * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 4800 LPM - 288 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 16 bar (from 1000 to 3600 rpm). Operating temperature range From 0 to 150 °C * Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Lubricated for life. Mounting arrangement Horizontal or vertical mounting (foot on demand). Inlet & Outlet connection DIN standard (ANSI on demand). Materials Casing/Flanges Cast Iron GG25 or GGG40. Screws Nitrided steel. O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk ATEX Zone 2 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PZ Series Technical Specifications 8 OUT IN 040-045 055-060 072 45° FLANGE IN-OUT Ø I G2 C D E F O Q P S G H R1 W A B R 61,5 63,6 Ø9 PZ 032 ONLY 032-040 045 M N L G1 N°2 M16 055-060 072 I1 k6 I2 I3 MOTOR FLANGE Shaft detail OPTION OPTION 032 45° Dimensions in mm unless otherwise stated. Model A B C D E F G G1 G2 H I I1 I2 I3 L M N O P Q R R1 S W 110 14 DN32 PZ032#3 182 288 150 // // 111 16 9 // 130 16 5 100 // 50 12 29 // // // 6 (h7) (k6) PN16 PZ040#3 100 19 DN50 194 353 220 // // 160 18 11 // 125 21.5 6 125 165 41 14 30 250 112 // 9 PZ045#3 (h7) (k6) PN16 PZ055#3 125 28 DN80 237 519 250 200 137 200 18 14 92.5 160 31 8 160 200 52 16 40 350 188 40 9 PZ060#3 (h7) (k6) PN16 160 32 DN100 PZ072#3 270 561 270 200 170 234 18 18 105 200 35 10 180 220 49 15 42 350 200 40 5 (h7) (k6) PN16 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PZ Series Technical Specifications Dimensions in mm unless otherwise stated. Model A B C D E F G G1 G2 H I I1 I2 I3 L M N O P Q R R1 S W PZ083#3 224 42 23 415 750 420 350 200 320 23.5 22 128 280 45 12 240 285 70 59 440 310 120 6 PZ102#3 (h7) (k6) 28 PZ126#3 972 340 50 DN250 30 6 570 620 445 275 470 25 26 197 420 53.5 14 355 406 110 97 544 400 150 PZ156#3 1001 (h7) (k6) PN16 33 6.5 N M Q W P O L G1 C B I3 G2 I2 H I R Option Option S F G OUT IN I1 k6 D E FLANGE IN-OUT MOTOR FLANGE A 083 102 126 156 R1 Shaft detail DN150 PN16 6" ANSI 150 9 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PZD Series Technical Specifications 10 For hydraulic oils, lubricating oils. Special version available for heavy fuel oils. Allowable delivery pressure (continuous) up to 16 bar from 750 to 1800 rpm Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Cargo, transfer, lubricating. Operating Data Handled fluid Fuel oil HFO - DO - LSMG0 - Hydraulic and Lube oils. Viscosity range From 1,2 to 5000 cSt (specific configuration may apply). Pump speed From 750 to 1750 rpm * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 10.000 LPM - 600 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 16 bar (from 1000 to 1750 rpm). Operating temperature range From 0 to 150 °C * Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Lubricated for life. Mounting arrangement Horizontal or vertical mounting (foot on demand). Inlet & Outlet connection DIN standard (ANSI on demand). Materials Casing/Flanges Cast Iron GGG40. Screws Nitrided steel. O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk ATEX Zone 2 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PZD Series Technical Specifications 11 Dimensions in mm unless otherwise stated. Model A B C D E F G H I J K K1 L L1 M N O P Q R S T T1 V PZD156 1050 530 390 169 50 335 480 160 400 M20 355 M24 480 405 700 54 16 450 530 M16 650 DN300 PN16 DN250 PN16 50 (k6) www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PXF Series Technical Specifications 12 For hydraulic oils, lubricating oils. Admissible delivery pressure (continuous) up to 30 bar at 1800 rpm. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Lubrication. Operating Data Handled fluid Hydraulic and Lube oils. Viscosity range From 10 to 5000 cSt * Pump speed From 750 to 3600 rpm * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 4800 LPM - 288 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 30 bar (from 102 to 156 up to 16 bar). Operating temperature range From 0 to 120 °C * Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication By pumped fluid. Mounting arrangement Horizontal or vertical mounting (foot on demand). Inlet & Outlet connection SAE up to size 083, DIN from size 102 to 156. Materials Casing/Flanges Cast Iron GG25 (standard), carbon steel on demand. Screws Nitrided steel. O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PXF - PXFE083 Series Technical Specifications Dimensions in mm unless otherwise stated. Model A A1 B C D E F H L L1 M IN OUT T V d1 d2 d3 d4 d5 d6 y PXF032#4 419 364 88 75 40 5 15 52 211 201 60 2" 1½" 21.5 6 19 125 160 145 120 13 45 PXF040#4 448 393 88 75 40 5 15 52 240 230 60 2" 1½" 21.5 6 19 125 160 145 120 13 45 PXF045#4 494 432 91.5 81 45 5 15 48.5 269 259 75.5 2½" 2" 35 10 32 125 160 145 138 13 50 PXF055#4 534 472 91.5 82 45 5 15 48.5 308 298 75.5 2½" 2" 35 10 32 125 160 145 138 13 50 PXF060#4 631 527 88 84 45 5 18 73.5 386 355 100 4" 2½" 35 10 32 160 200 195 174 18 50 PXF072#4 718 613 88 101 58 5 18 73.5 455 424 100 4" 2½" 35 10 32 160 200 195 174 18 50 SAE 3000 13 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PXF - PXFE083 Series Technical Specifications Dimensions in mm unless otherwise stated. Model A B C D E F H L N P T V d1 d2 d3 d4 d5 Z J Y W PXF083#3 632 154 128 80 5 25 77 350 43 12 40 250 315 365 26 289 13 264 186 (X) PXF102#3 690 170 145 80 5 30 233 375 43 12 40 250 315 365 26 327 18 300 178 (X) PXF126#3 808 180.5 143 80 5 30 237 484 43 12 40 250 315 365 26 343 18 320 231 (X) PXF156#3 896 250 186 97 5 39 300 460 53.5 14 50 340 420 470 26 - - - - DN 100 PN 16 SAE 4 DN 125 PN16 DN150 PN16 DN 150 PN16 DN125 PN16 DN 150 PN16 DN250 PN16 DN 1250 PN16 14 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PO - PWO Series Technical Specifications 15 For cooling lubricants with low viscosity and minimum lubricating properties (min. oil 4%). Admissible delivery pressure (continuous) 100 bar at 2900 rpm. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Boiler / burner. Operating Data Handled fluid Light fuel oils LFO, LSMGO - heavy fuel oils (HFO). Viscosity range From 1 to 15 cSt * Pump speed From 2900 to 3500 rpm. low lubricity fluids * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 650 LPM - 40 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 40 bar. Operating temperature range From 0 to 120 °C * Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Lubricated for life.. Mounting arrangement Horizontal or vertical (also vertical semi-submerged, thanks to the intermediate flange). Inlet & Outlet connection Suction port: BSP thread - Delivery port: SAE 3000. Materials Casing/Flanges Cast Iron Gg25, GGG-40 on request * Screws Nitrided steel * O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PO - PWO Series Technical Specifications Model A B C D E F H I L M IN OUT T V d1 d2 d3 d4 d5 d6 d7 X d8 d9 d10 Z PWO025 357 67 39 34 3 10 74 219 290 22 1" Gas 1" SAE 21.5 6 19 100 125 120 124 12 140 3 160 150 158 138 PWO025 357 67 39 34 3 10 74 219 290 22 1" Gas 1" SAE 21.5 6 19 100 125 120 124 12 140 3 160 150 158 138 PWO032 400 67 39 34 3 10 74 262 333 22 1" Gas 1" SAE 21.5 6 19 100 125 120 124 12 140 3 160 150 158 138 PWO040 484 102 49 40 7 15 81 312 383 42 1½" Gas 1½" SAE 27 6 22 125 160 154 158 14 180 6 215 203 211 173 PWO045 534 102 49 40 7 15 81 362 433 42 1½" Gas 1½" SAE 27 8 24 125 160 154 158 14 180 6 215 203 211 173 PWO055 613 161.5 64 55 8 15 100 380 451 72 3" Gas 2" SAE 35 10 32 125 160 173 175 14 235 6 265 249 257 232.5 PWO055 667 161.5 64 55 8 15 100 434 505 72 3" Gas 2" SAE 35 10 32 125 160 173 175 14 235 6 265 249 257 232.5 16 Dimensions in mm unless otherwise stated. Section www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps POF-PWOF Series Technical Specifications 17 For hydraulic oils, lubricating oils. Admissible delivery pressure (continuous) 120 bar at 2900 rpm. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Hydraulic oils, lubricating oils. Operating Data Handled fluid Lube oils, mineral and synthetic types. Viscosity range From 10 to 5000 cSt Pump speed From 2900 to 3500 rpm. * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 650 LPM - 40 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 40 bar. Operating temperature range * From 0 to 120 °C Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Lubricated for life.. Mounting arrangement Horizontal or vertical (also vertical semi-submerged, thanks to the intermediate flange). Inlet & Outlet connection Suction port: BSP thread - Delivery port: SAE 3000. Materials Casing/Flanges on request * Light alloy, GGG-40 Screws Nitrided steel * O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps POF-PWOF Series Technical Specifications Model A B C D E F H I L M N P T V d1 d2 d3 d4 d5 d6 d7 d8 d9 POF025#6 397 76 43 35 7 15 74.5 207 278 25 1" 1" 21.5 6 19 100 125 140 136 11 140 160 160 POF029#6 397 76 43 35 7 15 74.5 207 278 25 1" 1" 21.5 6 19 100 125 140 136 11 140 160 160 POF032#6 441 76 43 35 7 15 74.5 251 322 25 1" 1" 21.5 6 19 100 125 140 136 11 140 160 160 POF040#6 530 96 49 40 7 15 81 315 386 25 1½” 1½” 24.5 6 22 125 160 152 178 13 180 215 200 POF045#6 583 96 49 40 7 15 81 361 440 30 1½” 1½” 27 8 24 125 160 152 178 13 180 215 200 POF055#6 669 126 64 55 7 15 100 408 479 28 2" 3" 35 10 32 125 160 200 200 13 235 265 265 POF060#6 726 126 64 55 7 15 100 465 536 28 2" 3" 35 10 32 125 160 200 200 13 235 265 265 SAE 18 Dimensions in mm unless otherwise stated. www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps 2SP LS Series Technical Specifications 19 Non lubricating low and medium viscosity and corrosive fluids Suitable for water, light chemical and petrochemical products, fuel and heavy oils. Admissible delivery pressure (continuous) 10 bar at 1000 to 3600 rpm. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Cargo, transfer, lube system, stripping. Operating Data Handled fluid Fuel oil HFO - DO - LSMGO hydraulic and Lube oils. Viscosity range From 0.7 to 15.000 cSt Pump speed From 750 to 3600 rpm. * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 10,000 LPM - 600 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 40 bar. Operating temperature range * From 0 to 300 °C Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Dependent on application. Mounting arrangement Horizontal or vertical (with foot). Inlet & Outlet connection DIN standard (ANSI on request). Materials Casing/Flanges or carbon steel. GGG-40 Screws Nitrided steel * O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps 2SP LS Series Technical Specifications Model A B C D E F G1 G2 dGØ H M d1 Ø N l dl Ø nl O dOØ nO 2SP LS 090 850 300 450 180 350 75 180 250 22 32.5 8 28 24 3" ¾” 4 2" ¾” 4 2SP LS 110 850 300 450 180 350 95 180 250 22 40 8 30 26 3" ¾” 4 2" ¾” 4 2SP LS 130 950 350 525 225 375 110 200 300 26 50 10 35 30 4" ¾” 8 3" ¾” 4 7 2SP LS 170 1075 400 575 280 410 125 230 350 26 65 12 40 35 5" / 8” 8 4" ¾” 8 7 7 2SP LS 210 1200 475 700 315 450 133 260 410 34 80 14 50 44.5 6" / 8” 8 5" /8” 8 7 7 2SP LS 270 1350 575 850 400 500 150 300 475 34 100 18 60 53 6" / 8” 8 5" /8” 8 Dimensions in mm unless otherwise stated. IN OUT 20 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps 2SP Series Technical Specifications 21 Non lubricating low and medium viscosity and corrosive fluids Suitable for water, light chemical and petrochemical products, fuel and heavy oils. Admissible delivery pressure (continuous) 16 bar at 1000 to 3600 rpm. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Cargo, transfer, lube system, stripping. Operating Data Handled fluid Fuel oil HFO - DO - LSMGO hydraulic and Lube oils. Viscosity range From 0.7 to 15.000 cSt Pump speed From 750 to 3600 rpm. * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 20,000 LPM - 1200 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 40 bar. Operating temperature range * From 0 to 300 °C Seal Mechanical seal. Bearing type Radial ball on main shaft. Bearing lubrication Dependent on application. Mounting arrangement Horizontal or vertical (with foot). Inlet & Outlet connection DIN standard (ANSI on request). Materials Casing/Flanges or carbon steel. GGG-40 Screws Nitrided steel * O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps 2SP - L2 Series Technical Specifications Dimensions in mm unless otherwise stated. IN OUT Model A B C D E F G1 G2 dG Ø H1 H2 L M d1 Ø N P Q R S l dlØ nl O dO Ø nO 7 7 2SP090 1050 720 800 505 410 285 360 380 22 300 255 70 8 28 24 535 515 360 32.5 8" / 8” 8 6" /8” 8 7 7 2SP110 1050 720 800 505 410 285 360 380 22 300 255 70 10 32 27 535 515 360 40 8" / 8” 8 6" /8” 8 7 2SP130 1100 760 850 585 450 300 380 400 26 330 280 82 12 40 35 560 540 380 50 10" 1" 12 8" / 8” 8 2SP170 1300 1000 1000 660 460 355 420 440 26 380 315 90 16 55 49 665 635 500 65 12" 1" 12 10" 1" 12 1 2SP210 1500 1100 1100 785 520 410 450 475 34 480 400 104 18 65 58 770 730 550 80 16" 1 / 8” 16 12" 1" 12 1 1 2SP270 1800 1320 1300 910 600 490 530 555 34 550 450 125 20 70 62.5 920 880 660 100 20" 1 / 4” 20 16 1/8” 16 22 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps 2SP - L3 Series Technical Specifications Dimensions in mm unless otherwise stated. IN OUT Model A B C D E F G1 G2 dG Ø H1 H2 L M d1 Ø N P Q R S l dlØ nl O dO Ø nO 7 7 2SP090 1205 720 800 505 410 360 360 380 22 300 255 70 8 28 24 615 590 360 32.5 8" / 8” 8 6" /8” 8 7 7 2SP110 1210 720 800 505 410 365 360 380 22 300 255 75 10 32 27 615 595 360 40 8" / 8” 8 6" /8” 8 7 2SP130 1265 760 850 585 450 380 380 400 26 330 280 82 12 40 35 645 620 380 50 10" 1" 12 8" / 8” 8 2SP170 1470 1000 1000 660 460 440 420 440 26 380 315 90 16 55 49 750 720 500 65 12" 1" 12 10" 1" 12 1 2SP210 1675 1100 1100 785 520 500 450 475 34 480 400 104 18 65 58 855 820 550 80 16" 1 / 8” 16 12" 1" 12 1 1 2SP270 1975 1320 1300 910 600 580 530 555 34 550 450 125 20 70 62.5 1005 970 660 100 20" 1 / 4” 20 16 1/8” 16 23 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

24 L1 One mechanical seal package; lubricating fluids only. Lube oil Fuel oil Hydraulic Oil. Every fluid with lubricant characteristics. Self priming, double entry design, with internal bearings and synchronised timing gear. One mechanical or packing seal. » Working temperature up to 100°C. » Viscosity range up to 1500 cSt. » Inlet pressure up to 6 bar. » Differential pressure up to 16 bar. » Speed up to 3500 rpm. L2 Four “component” mechanical seal packages. Non lubricating low and medium viscosity and corrosive fluid. Self priming, double entry design, with external bearings separated by seals. Compact design for a simple maintenance and cheapest solution. Shaft seal shall be single or double. » Working temperature up to 150°C. » Viscosity range up to 1500 cSt. » Inlet pressure up to 6 bar. » Differential pressure up to 16 bar. » Speed up to 3500 rpm. L3 Four “cartridge” mechanical seal. Non lubricating low and medium viscosity and corrosive and dangerous fluids. Self priming, double entry design, with external bearings separated by seals. Long shaft design suitable for a wide range of seals. Possibility of cartridge design installation. » Working temperature up to 200°C. » Viscosity range up to 2500 cSt. » Inlet pressure up to 6 bar. » Differential pressure up to 16 bar. » Speed up to 3500 rpm. L4 Four API 682 mechanical seal. Non lubricating low and medium viscosity, corrosive and dangerous fluids in heavy duty service with operating more than 3 year. Self priming, double entry design, with external bearings separated by seals. Strong shaft design for all dangereous fluids in all conditions. Design to meet API 676 and all API 682 mechanical seal configurations. Possibility to work in mixed phases. » Working temperature up to 300°C. » Viscosity range up to 15000 cSt. » Inlet pressure up to 10 bar. » Differential pressure up to 40 bar. » Speed up to 3500 rpm. Are available in four different arrangements suitable to match most of the applications. Custom versions available on request. SCREW PUMPS Screw Pumps Twin Screw 2SP Series Screw Pumps www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps MPV2 Series Technical Specifications For hydraulic or lubricating oils. Maximum pressure 40 bar or 200 bar (depending by flow meter dimension).. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application Fuel consumption, control cargo and transfer flow. Technical Characteristics Delivery flow Up to 7.000 LPM - 420 m3/h (standard version Pressure Versions nominal pressure 40bar or 200bar Admissible temperature -15 to +150°C Precision Class 0,2% Type of O/P Square wave signal in frequency, direct function of flow rate* Materials Casing GGG-40 or carbon steel, aluminium Flanges Carbon steel Screws Nitrided steel * O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk Connection Size Size Qminimum (lpm) Q nominal (lpm) Q maximum (lpm) Version Flange Threaded 22 0.4 48.8 73.0 SAE 3000 - 1¼” G1" Standard 40 2.9 291 436.5 SAE 3000 - 2" G1½” Standard 62 10.8 1,078 1,617 SAE 3000 - 3" G2½” Standard 80 20.8 2,082 3,124 DN100 - PN40 G4" Standard 120 47.0 4,695 7,043 DN150 - PN40 X Standard 240 197.0 19,690 29,534 On request X On request 25 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps MPV2 Series Technical Specifications Dimensions in mm unless otherwise stated. Flow Meter Size A B C C1 F SAE/DN D E Maximum Pressure (bar) 022 158 79 30.2 58.7 - SAE1¼ 3000 psi M10 1" 40 040 230 109 42.9 77.8 - SAE 2" 3000 psi M12 1½” 200 when connected with SAE flange 062 335 200 61.9 106.4 - SAE3" 3000 psi M16 2¼” 200 (140 ) 080 396 235 - - 190 DN100 PN40 M20 4" 40 120 522 300 - - 220 DN150 PN40 M22 - 40 A ØB Alternative mounting SAE or DN flange (see dimensional chart) C (SAE) C1 (SAE) ØF (DN) D (metric thread) D (metric thread) E (GAS thread) E (GAS thread) MPV2 080 - 120 DN connection MPV2 022 - 040 - 062 SAE connection AVAILABLE COMPLETE SYSTEMS for CUSTOMIZED fuel consumption control complete of: » » Single Control system (after Feeder pump). Remote Display (Control Room) via Ethernet, Wi-Fi. » » Single Control System for Flow difference (after circulation pump - fuel motor return). Data transmission to the Control Room. » » Control Systems for two or more Diesel Engines. Data transmission to Land Office (Internet, GSM, satellite). » » Local display (Engine Room). Warning Service (SMS, E-mail). 26 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PDP Series Technical Specifications 27 Double pump station for fuel oil. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application . Booster, Feeder, Fuel supply Operating Data Handled fluid Fuel oil HFO - DO - LSMGO hydraulic and Lube oils. Viscosity range From 1,2 to 5000 cSt Pump speed From 750 to 3600 rpm. * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 200 LPM - 12 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 16 bar (from 1000 to 3600 rpm) Operating temperature range From 0 to 150 °C (*) Inlet & Outlet connection DN40 ANSI 150 Cartridge filtration / surface 500 micron / 500 cm2 MATERIALS Casing/Flanges Modular cast Iron GGG40 O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps PDP Series Technical Specifications 28 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps SPB Series Technical Specifications 29 Double pump station for fuel oil. Installation Data Installation Indoor or Outdoor. Environment Marine, Industrial. Application . Boiler, burner Operating Data Handled fluid Fuel oil HFO - DO - LSMGO Hydraulic and lube oils. Viscosity range From 1,2 to 5000 cSt Pump speed From 750 to 3600 rpm. * Rotation (viewed from coupling end) CW (Std version; CCW on demand). Technical Characteristics 3 Flow rate Up to 41 LPM - 2.5 m /h. Suction pressure From - 0,5 to 10 bar. Delivery pressure Up to 16/40 bar (from 1000 to 3600 rpm) Operating temperature range From 0 to 150 °C (*) Inlet & Outlet connection DN32 PN40 Cartridge filtration / surface 100 micron / 150 cm2 MATERIALS Casing/Flanges Modular cast Iron GGG40 O-rings Viton ® Surface protection On request. *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps SPB Series Technical Specifications 30 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

SCREW PUMPS Screw Pumps Magnetic Coupling Drive 31 Installation Data Applicable to all PUMPS SIZE: PB series (from 3 to 41 lpm) at 16 / 40 bar PHS series (from 6 to 200 lpm) at 16 bar PZ series (from 30 to 4.800 lpm) at 16 bar More usual applications: FUEL SUPPLY: Cargo, Transfer, Separator, Feeder, Circulating, Boiler/Burner Operating Data Handled Fluids: HFO, DO, GO, LSMGO (all fluids with some lubricant properties but dangerous in case of leakage) Minimum viscosity: From 1,2cSt *Contact jbj Techniques technical office for different values, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk Advantages » Safety » System efficiency » Regulations compliance » Reliability » Performance with low sulfur and low viscosity fluid » Cuts maintenance costs as there is no mechanical seal No Mechanical Seal No Parts In Contact Sealed System www.jbj.co.uk/screwpumps.html #DriveLineHarmony

Screw Pumps Performance Chart SCREW PUMPS 20,000 - 1,200 10,000 - 600 4,800 - 288 1,400 - 84 1,300 - 78 650 - 39 560 - 33.6 420 - 25 200 - 12 100 - 6 41 - 2.46 30 - 1.8 11 - 0.66 9 - 0.54 6 - 0.36 3 - 0.18 Speed rotation to be evaluated 3 Capacity (l/min - m ) Viscosity range (cSt) Model pump Nominal pressure (bar) Application 1.2 - 5,000 PB PN16 PN16 PN16 PN16 PN30 PN40 PN120 PN100 Special sizes PN16/PN40 PN16/PN40 Fuel and diesel oil pump Lube oil pump Boiler pump Hydraulic pump Transfer* Transfer* 1.2 - 5,000 PHS 1.2 - 5,000 PZ 1.2 - 5,000 PZD 10 - 5,000 PXF 1 - 15 PWO fuel 10 - 5,000 PWOF oil 10 - 400 PWOF oil 0.7 - 15,000 Twin 2SP LS 0.7 - 15,000 Twin 2SP Max. 3,600 rpm Max. 3,600 rpm Up to 072 pump size max. 3,600 rpm / over max.1,800 rpm Max. 1.800 rpm Up to 072 pump size max. 3,600 rpm / over max.1,800 rpm Max. 3,600 rpm Max. 3,600 rpm Max. 1800 rpm Speed rotation to be evaluated 32 www.jbj.co.uk/screwpumps.html #DriveLineHarmony

Getting the most out of your machinery often depends on close integration between all components. An organisation that manufactures and integrates all the diverse components of a drivetrain provides the experience to help you select the best component combination for your application. jbj Techniques’ in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The following examples are a simplistic view of how jbj Techniques assists customers. Hydraulic Adaptors Designed primarily to allow the close coupling of hydraulic pumps to a variety of prime movers, such as diesel / petrol engines, electric, air or hydraulic motors, they can also be used in the connection from prime mover to alternative driven parts i.e. gear boxes, generators, water or vacuum pumps etc. An additional range of engine front PTO adaptors, which provide additional connection between the engine pulley and the driven part are also available. The kit comprises of a and flexible bellhousing drive that are fully machined to suit the coupling driving and driven components. These can be to suit either shaft to shaft, flange (flywheel) to shaft or even flange to flange connections. Getting the most out of your equipment will demand close integration between all components. In specifying jbj Techniques as your preferred supplier, you will have selected a company with the experience to specify, manufacture and integrate all of the diverse components that will ensure the best component combination for your application. jbj's in house design team and manufacturing facility provide tailored solutions for your applications at competitive pricing and on-time deliveries. Pump shaft alignment is key to preventing unnecessary wear and damage to the pump shaft seal and bearing. Improper alignment may lead to premature pump failure. Also to be considered are unwanted torsional resonant frequencies in the system which can quickly cause damage to components in the drivetrain and reduce system life and performance. Improper pump installation can lead to premature failure, increased maintenance costs and reduced production levels of final product. jbj Techniques can advise on the correct installation of into Industrial / hydraulic pumps mobile / marine / machine tool / agricultural / offshore industries and can specify complete driveline systems from their extensive range of components which are available from stock or manufactured to order, albeit simple or complex, standard or bespoke. Electric Motor – Hydraulic Pump Adaptors (safe area) jbj Techniques Limited offer the most comprehensive range of in Europe. bellhousings Designed to connect electric motors with frame size IEC D56 - D400 (0.06kW – 750kW) and can be compatible with electric motor 'B5' or 'B14' flange configurations. Accompanying the metric frame units above is a complete range of mountings to suit Nema and imperial frame motors with 'C' face or 'D' flange fitments. With fully machined , torsionally flexible couplings or available, jbj ensure torsionally rigid couplings the most suitable combination is selected for the application in hand. As an example spider couplings are available in various materials including aluminium, grey cast iron, nodular iron, steel and stainless steels and can be finish machined with parallel, taper or splined bores to DIN, SAE, ANSI or ISO standards. Bellhousings can be manufactured in aluminium or cast iron material as standard, however, units can be produced in a variety of exotic materials on request. The aluminium product range is produced in either monoblock or composite formats giving great flexibility in design and allows for early delivery time, often with same or next day delivery possibilities. For applications where low noise levels are a quality products for mechanical & fluid power #DriveLineHarmony www.jbj.co.uk an excellence in engineering

ensuring a continuing high quality service in which customers can have complete confidence. “ “ requirement then a complete range of antivibration and noise reduction components add to the range. Electric motor – Hydraulic Pump Adaptors (hazardous area) Designed to meet the exacting safety standards of the offshore and chemical process industries, jbj Techniques produce certificated to adaptor kits Directive 2014/34/EU II2GD-IM2-TX -50 C< Service Temp < +105 C. Harmonised standards BS EN 1127:1, BS EN 13463:1, BS EN13463:5, BS EN 50303, BS EN 1834-1,BS EN 1834-3. Generally manufactured in Cast or Nodular iron, bellhousings can be produced in steel, stainless steel or alternative exotic materials on customer request. Couplings supplied for these applications are the jbj Techniques 'JXL' pin and bush range which provide an anti-static and flameproof drive which meet zone 1 area requirements, conforming to all of the above standards. Also available are spider and gear couplings which are certified to zone 2 standards. (Contact jbj Techniques for details). An important development of equipment for use within hazardous areas is the wet mount series of bellhousings. Commissioned to research and develop a product that would control the high temperature generated by a piston pump shaft seal when working within cycling applications. A little considered issue is the frictional heat generated at the shaft seal when the application requires the pump to cycle between different pressures causing the seal temperature to increase. This process will often take the seal temperature out and above the levels required by the relevant ATEX standards requirement. This specially designed assembly allows a pumped cooling flow to be passed over the seal face and through an auxiliary cooler, this in turn reduces the seal face temperature which can be maintained at an acceptable level. With a vast array of components to select from, jbj are well placed to provide all required components to support the required cooling system. Diesel Engine – Hydraulic Pump Adaptors A complete range of bellhousing and couplings exist for the connection of a diesel engine flywheel to a specified driven component, be it an oil hydraulic pump, water pump, generator or similar device. With the bellhousing available in various materials to suit all application areas. With a standard range to connect Diesel engines with SAE dimensions from SAE '6' to SAE '0' jbj are well placed to satisfy the majority of customer requirements. Couplings to complete the assembly are available in either torsionally flexible or torsionally rigid design ad can be supplied to suit SAE flywheel dimensions from SAE 6.5” to SAE 18”. For hydraulic pumps to be mounted to engines that do not conform to SAE dimensions, we offer a full range of assembly parts, some of which (but not all) are shown here » for diesel engines All bellhousings within this range can be finished machined to accept any, piston, vane or gear pump interfaces requested by customer. As with the electric motor range of product jbj offer complete solutions for ATEX environments, using our well proven 'JXL' coupling range which has standard design to connect to the engine flywheel. Directive 2014/34/EU II2GD-IM2-TX -50°C ≤ Service Temp ≤ +105°C. Harmonised Standards: BS EN 1127:1 BS EN 13463:1 BS EN 13463:5 BS EN 50303. Petrol Engine – Hydraulic Pump Adaptors Petrol engine adaptors have been developed for use with industrial petrol engines. Design exists to suit Honda, Briggs and Stratton, Kawasaki, Kubota, Hatz, Mag, Robin, Suzuki, Winsconsin, to name but a few, all adaptors can be finished to accept most hydraulic pumps. Adaptors to suit engine crankshaft drives and for vertical mounting are available on request. #DriveLineHarmony www.jbj.co.ukl to Large Combinations Small Individual Components

to Large Combinations from Small Individual Components ensuring a continuing high quality service in which customers can have complete confidence. “ “ # Driveline jbj Techniques is a specialist supplier of high-quality products for the mechanical power transmission and fluid power sectors. The company offers a high level of in-house expertise plus a huge selection of products to meet a very broad range of customer applications. From specification, through technical advice and manufacture to after-sales support, jbj Techniques provides a comprehensive and valued service to the power transmission and hydraulics industries. The company fields a UK-wide team of technical sales engineers to ensure that the business is close to its customers, and it enjoys excellent associations with European manufacturers, acting as sole UK distributor in many cases. jbj’s team is recognised for its expertise in the selection and configuration of hydraulic and mechanical transmission systems. Able to draw on an that extensive product range provides the building blocks for bespoke systems both large and small, the in-house design team offers a complete service, ranging from an assessment of customer requirements to full technical backup, including product specification, CAD based system design, system build and certification. Moreover customers can take advantage of jbj’s own machine-shop facilities and skilled engineers guarantee to quality and control costs. jbj Techniques provides one of the widest ranges of couplings available within the UK; mechanical power transmission couplings for a vast range of applications. Ranging from miniature couplings, all steel gear couplings, flexible spider couplings, shaft couplings, torque limiting couplings, disc and grid type couplings, ATEX compliant and shaft locking devices. Magnetic couplings for power transmission between hermetically sealed areas. However as extensive as the selection is, couplings make up a fraction of jbj’s portfolio. As power transmission specialists the company stock and provide gearboxes, clutches, pumps, hydraulic motors, flow meters, fluid power accessories including: cooling & heat exchange products, reservoirs, pipe flanges, seals and level indicators, as well as a variety of bellhousings and engine adaptors, to name just a few of the product categories. jbj Techniques Limited is proud of it’s relationship and reputation with customers and suppliers. The core client base is stable and loyal, which is testament to the quality of service provided by the company. A similar relationship exists with suppliers, ensuring a continuing high quality service in which customers can have complete confidence. Dampers Engine Adaptor Kits Hydraulic Adaptors Torque Limiting Couplings Tyre Couplings Anti-static/Flameproof Couplings Torsionally Rigid Couplings Torsionally Flexible Couplings Bellhousings Permanent Magnetic Couplings Torsional Couplings

ne Harmony comprehensive range of components www.jbj.co.uk an excellence in engineering 01737 767493 info@jbj.co.uk www.jbj.co.uk - registered in England No: 1185469 - jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/E requirements Screw Pumps Pneumatic Motors & Starters Gear Pumps/Motors Axial & Radial Piston Motors Vane Pumps LSHT Motors/Geared Motors Splitter Gearboxes Planetary Gearboxes BDS Clutches BD Clutches & Gearboxes Oil Bath Clutches Flow Dividers Tanks/Accessories Fluid Level Indicators Flanges Mini Power Packs Coolers Pressure Intensifiers You Tube

registered in England No: 1185469 jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/EC requirements set by James Harris, jbj Techniques Limited jbj Techniques Limited 28 Trowers Way Holmethorpe Industrial Estate Redhill Surrey RH1 2LW. UNITED KINGDOM 01737 767493 info@jbj.co.uk www.jbj.co.uk quality products for mechanical & fluid power You Tube
