www.jbj.co.uk/bearing-supported-stub-shafts.html 1 #DriveLineHarmony Stub shaft drive plates fit SAE depressed centre flywheels. They are designed for use with a flexible coupling to direct drive auxiliary components. See L-Series or flexible couplings for shaft-to-shaft adaptor to fit your application. Side loading requires the use of a pillow block bearing or supported stub shaft option. When placing an order, please use the part number listed below. NOTE: Stub shafts for the SAE 14 clutches and larger are available on a non-stock basis. Special sizes, diameters and shaft lengths (keyed and overall) are available upon request. SAE 4 & 5 Side Load Plates available from stock. Contact jbj Techniques technical office, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk for more details. If it is determined that your assembly needs greater side load capabilities than a straight shaft and single bearing design, please contact us to discuss the use of our exclusive bearing supported stub shafts as described in the following pages. 26-01A52 7.50 95.25 mm (3.75") 152.4 mm (6") 38.1 mm (1.50") ³⁄ " 26-02S53 8 Special Special Special Special 26-0AA52 7.50 95.25 mm (3.75") 152.4 mm (6") 36.51 mm (1.4375") ³⁄ " Stub Shaft Drive Plates Part Number SAE Clutch Size Keyed Shaft Overall Length Shaft Ø Key Size 26-02A52 7.50 95.25 mm (3.75") 152.4 mm (6") 44.45 mm (1.75") ³⁄ " 26-01G54 10 95.25 mm (3.75") 152.4 mm (6") 38.1 mm (1.50") ³⁄ " 26-03B54 10 136.53 mm (5.375") 203.2 mm (8") 50.80 mm (2") ¹⁄ " 26-01A53 8 Special Special Special Special 26-01A51 6.50 95.25 mm (3.75") 152.4 mm (6") 38.1 mm (1.50") ³⁄ " 26-04A55 11.5 95.25 mm (3.75") 152.4 mm (6") 57.15 mm (2.25") ¹⁄ " 26-05A55 11.5 95.25 mm (3.75") 152.4 mm (6") 63.50 mm (2.5") ⁵⁄ " 26-02B64 10 136.53 mm (5.375") 203.2 mm (8") 44.45 mm (1.75") ³⁄ " 26-03G54 10 95.25 mm (3.75") 152.4 mm (6") 50.80 mm (2") ¹⁄ " 26-02A51 6.50 95.25 mm (3.75") 152.4 mm (6") 44.45 mm (1.75") ³⁄ " Features and advantages » Custom shafts. » Standard SAE. » Tapered generator shafts. » Single bearing supports (Light Loads). » Various sizes from 36.51 mm (1⁷⁄ ″) to 63.50 mm (2¹⁄ ″). » Approved by many engine manufactures. » Very cost effective for in-line applications. Mechanical Power Transmission SAE Stub Shafts » Band saws » Compressors » Concrete trowel » Stump grinders » Generators … and much more. Applications » Chippers
Mechanical Power Transmission Bearing Supported Stub Shafts www.jbj.co.uk/bearing-supported-stub-shafts.html 2 #DriveLineHarmony This stub shaft design employs a single and double roll radial ball bearing designed for light and heavy-duty work, not to exceed side loads listed in tables 1 to 4 on the following page 3. The bearings are self-contained in our specially designed housing that will keep the assembly free of contamination. These supported stub shafts come pre-mounted to your specific flywheel housing plate or custom housing. The package includes a mounted bearing support and flywheel coupling that will be sized to your application to drive the bearing support sub-assembly. We emphasize that the data contained herein should be used as a guide only. The tabulation is based on laboratory tests but does not take into account all variables that can be encountered in actual use. All applications are individual, no two are identical in setup or environmental conditions after all. Therefore, it is advisable to test the material under actual service conditions before specification. If this is not practical, tests should be devised that simulate your service conditions as closely as possible. Important Note: The bearing support must be greased every 2000 hours to ensure bearing life. Specifically designed for side load applications. Output: Depends on your application for shaft size and length. Ratings: Input torque (max.): 881 Nm (650 lb-ft). Input / output speed: 3000 rpm. Power (Max.): 261 kW (350 HP). Bearings: 3 years continuous running. 76.2 mm (3") or 127mm (5") 36.5 mm (1⁷⁄ ") 38.1 mm (1¹⁄ ") 50.8 mm (2") 63.5 mm (2¹⁄ ") Splined coupling to drive stub shaft Grease fill Heavy duty double row bearing Depends on shaft diameter and length Depends on shaft diameter Relief valve
Table 1: Side Load Ratings for 36.51 mm (1⁷⁄ ") Bearing Supported Stub Shaft (Tapped for Centrifugal Clutch) Side load (1000 lbs) (1000 lbs) (1000 lbs) (1000 lbs) (1000 lbs) (950 lbs) (910 lbs) (870 lbs) (810 lbs) Basic L-10 91468 57168 41577 32667 26902 26671 26387 26712 28686 453.6 kgs 453.6 kgs 453.6 kgs 453.6 kgs 453.6 kgs 430.9 kgs 412.8 kgs 394.6 kgs 367.4 kgs Life Hours 500 rpm 800 rpm 1100 rpm 1400 rpm 1700 rpm 2000 rpm 2300 rpm 2600 rpm 3000 rpm Side load (1500 lbs) (1240 lbs) (1160 lbs) (1075 lbs) (1000 lbs) (950 lbs) (910 lbs) (870 lbs) (810 lbs) Life Hours 500 rpm 800 rpm 1100 rpm 1400 rpm 1700 rpm 2000 rpm 2300 rpm 2600 rpm 3000 rpm Basic L-10 27102 29984 26636 26296 26902 26671 26387 26712 28686 Table 2: Side Load Ratings for 38.1 mm (1¹⁄ ") Bearing Supported Stub Shaft (Tapped for Centrifugal Clutch) 680.4 kgs 562.5 kgs 526.2 kgs 487.6 kgs 453.6 kgs 430.9 kgs 412.8 kgs 394.6 kgs 367.4 kgs Mechanical Power Transmission Bearing Supported Stub Shafts Life Hours Side load Table 3: Side Load Ratings for 50.8 mm (2") Bearing Supported Stub Shaft (Tapped for Centrifugal Clutch) (2600 lbs) (2300 lbs) (2175 lbs) (2025 lbs) (1900 lbs) (1810 lbs) (1740 lbs) (1680 lbs) (1580 lbs) Basic L-10 31994 30091 26365 26287 26770 26750 26529 26380 28052 500 rpm 800 rpm 1100 rpm 1400 rpm 1700 rpm 2000 rpm 2300 rpm 2600 rpm 3000 rpm 1179.3 kgs 1043.3 kgs 986.6 kgs 918.5 kgs 861.8 kgs 821.0 kgs 789.3 kgs 762.0 kgs 716.7 kgs Table 4: Side Load Ratings for 63.5 mm (2¹⁄ ") Bearing Supported Stub Shaft (Tapped for Centrifugal Clutch) 500 rpm 800 rpm 1100 rpm 1400 rpm 1700 rpm 2000 rpm 2300 rpm 2600 rpm 3000 rpm Basic L-10 32314 30014 26679 27075 26404 26847 26901 26789 28597 2199.9 kgs 1927.8 kgs 1803.0 kgs 1655.6 kgs 1564.9 kgs 1474.2 kgs 1406.1 kgs 1351.7 kgs 1261.0 kgs Life Hours (4850 lbs) (4250 lbs) (3975 lbs) (3650 lbs) (3450 lbs) (3250 lbs) (3100 lbs) (2980 lbs) (2780 lbs) Side load www.jbj.co.uk/bearing-supported-stub-shafts.html 3 #DriveLineHarmony IMPORTANT: If you have an application that you feel is not covered by this data please contact the jbj Technical office, telephone: +44 (0)1737 767493 or email: info@jbj.co.uk to determine what can be done. Remember these loads are calculated for 3 years of continuous running. If you are not running the unit 24 hours a day 7 days a week youmay be able to have a higher load at higher RPM’s.
» Very cost effective for side load adapters. » Chippers. » Compressors. » Concrete saws. » Rollers. » Any side load application. » Various sizes from 36.51 mm (1⁷⁄ ″) to 63.5 mm (2¹⁄ ″). » Short lead times on non-stock assemblies. Applications Features and advantages » Rugged double bearing design. » Easy installation. » Re-greasable for long life. » Oil filled assemblies for 24 hour use. Our bearing supported stub shafts are used on off-highway equipment such as: » Band saws. » Stump grinders. » Concrete trowels. » Pulley and belt drives. … and much more. HEX-FLX Bearing Supports are NOT APPROVED FOR GENERATOR, VACUUM PUMP OR BLOWER APPLICATIONS. This is where our generator drives come in (see facing page). Mechanical Power Transmission HEX-FLX Bearing Supports www.jbj.co.uk/bearing-supported-stub-shafts.html 4 #DriveLineHarmony
Mechanical Power Transmission Generator Drives » Easy installation. Features and advantages » Rugged housing. » Approved by many engine manufactures. » Strong tapered shaft design. » Very cost effective. » Various sizes. » Custom alignment. Applications Generator setups, custom auxiliary power units (APU’s) providing energy for functions other than propulsion. www.jbj.co.uk/bearing-supported-stub-shafts.html 5 #DriveLineHarmony
Getting the most out of your machinery often depends on close integration between all components. An organisation that manufactures and integrates all the diverse components of a drivetrain provides the experience to help you select the best component combination for your application. jbj Techniques’ in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The following examples are a simplistic view of how jbj Techniques assists customers. Hydraulic Adaptors Designed primarily to allow the close coupling of hydraulic pumps to a variety of prime movers, such as diesel / petrol engines, electric, air or hydraulic motors, they can also be used in the connection from prime mover to alternative driven parts i.e. gear boxes, generators, water or vacuum pumps etc. An additional range of engine front PTO adaptors, which provide additional connection between the engine pulley and the driven part are also available. The kit comprises of a and flexible bellhousing drive that are fully machined to suit the coupling driving and driven components. These can be to suit either shaft to shaft, flange (flywheel) to shaft or even flange to flange connections. Getting the most out of your equipment will demand close integration between all components. In specifying jbj Techniques as your preferred supplier, you will have selected a company with the experience to specify, manufacture and integrate all of the diverse components that will ensure the best component combination for your application. jbj's in house design team and manufacturing facility provide tailored solutions for your applications at competitive pricing and on-time deliveries. Pump shaft alignment is key to preventing unnecessary wear and damage to the pump shaft seal and bearing. Improper alignment may lead to premature pump failure. Also to be considered are unwanted torsional resonant frequencies in the system which can quickly cause damage to components in the drivetrain and reduce system life and performance. Improper pump installation can lead to premature failure, increased maintenance costs and reduced production levels of final product. jbj Techniques can advise on the correct installation of into Industrial / hydraulic pumps mobile / marine / machine tool / agricultural / offshore industries and can specify complete driveline systems from their extensive range of components which are available from stock or manufactured to order, albeit simple or complex, standard or bespoke. Electric Motor – Hydraulic Pump Adaptors (safe area) jbj Techniques Limited offer the most comprehensive range of in Europe. bellhousings Designed to connect electric motors with frame size IEC D56 - D400 (0.06kW – 750kW) and can be compatible with electric motor 'B5' or 'B14' flange configurations. Accompanying the metric frame units above is a complete range of mountings to suit Nema and imperial frame motors with 'C' face or 'D' flange fitments. With fully machined , torsionally flexible couplings or available, jbj ensure torsionally rigid couplings the most suitable combination is selected for the application in hand. As an example spider couplings are available in various materials including aluminium, grey cast iron, nodular iron, steel and stainless steels and can be finish machined with parallel, taper or splined bores to DIN, SAE, ANSI or ISO standards. Bellhousings can be manufactured in aluminium or cast iron material as standard, however, units can be produced in a variety of exotic materials on request. The aluminium product range is produced in either monoblock or composite formats giving great flexibility in design and allows for early delivery time, often with same or next day delivery possibilities. For applications where low noise levels are a quality products for mechanical & fluid power #DriveLineHarmony www.jbj.co.uk an excellence in engineering
ensuring a continuing high quality service in which customers can have complete confidence. “ “ requirement then a complete range of antivibration and noise reduction components add to the range. Electric motor – Hydraulic Pump Adaptors (hazardous area) Designed to meet the exacting safety standards of the offshore and chemical process industries, jbj Techniques produce certificated to adaptor kits Directive 2014/34/EU II2GD-IM2-TX -50 C< Service Temp < +105 C. Harmonised standards BS EN 1127:1, BS EN 13463:1, BS EN13463:5, BS EN 50303, BS EN 1834-1,BS EN 1834-3. Generally manufactured in Cast or Nodular iron, bellhousings can be produced in steel, stainless steel or alternative exotic materials on customer request. Couplings supplied for these applications are the jbj Techniques 'JXL' pin and bush range which provide an anti-static and flameproof drive which meet zone 1 area requirements, conforming to all of the above standards. Also available are spider and gear couplings which are certified to zone 2 standards. (Contact jbj Techniques for details). An important development of equipment for use within hazardous areas is the wet mount series of bellhousings. Commissioned to research and develop a product that would control the high temperature generated by a piston pump shaft seal when working within cycling applications. A little considered issue is the frictional heat generated at the shaft seal when the application requires the pump to cycle between different pressures causing the seal temperature to increase. This process will often take the seal temperature out and above the levels required by the relevant ATEX standards requirement. This specially designed assembly allows a pumped cooling flow to be passed over the seal face and through an auxiliary cooler, this in turn reduces the seal face temperature which can be maintained at an acceptable level. With a vast array of components to select from, jbj are well placed to provide all required components to support the required cooling system. Diesel Engine – Hydraulic Pump Adaptors A complete range of bellhousing and couplings exist for the connection of a diesel engine flywheel to a specified driven component, be it an oil hydraulic pump, water pump, generator or similar device. With the bellhousing available in various materials to suit all application areas. With a standard range to connect Diesel engines with SAE dimensions from SAE '6' to SAE '0' jbj are well placed to satisfy the majority of customer requirements. Couplings to complete the assembly are available in either torsionally flexible or torsionally rigid design ad can be supplied to suit SAE flywheel dimensions from SAE 6.5” to SAE 18”. For hydraulic pumps to be mounted to engines that do not conform to SAE dimensions, we offer a full range of assembly parts, some of which (but not all) are shown here » for diesel engines All bellhousings within this range can be finished machined to accept any, piston, vane or gear pump interfaces requested by customer. As with the electric motor range of product jbj offer complete solutions for ATEX environments, using our well proven 'JXL' coupling range which has standard design to connect to the engine flywheel. Directive 2014/34/EU II2GD-IM2-TX -50°C ≤ Service Temp ≤ +105°C. Harmonised Standards: BS EN 1127:1 BS EN 13463:1 BS EN 13463:5 BS EN 50303. Petrol Engine – Hydraulic Pump Adaptors Petrol engine adaptors have been developed for use with industrial petrol engines. Design exists to suit Honda, Briggs and Stratton, Kawasaki, Kubota, Hatz, Mag, Robin, Suzuki, Winsconsin, to name but a few, all adaptors can be finished to accept most hydraulic pumps. Adaptors to suit engine crankshaft drives and for vertical mounting are available on request. #DriveLineHarmony www.jbj.co.ukl to Large Combinations Small Individual Components
