ELIKA1 P Available displacement 3 3 from 2.1 cm /rev to 8.1 cm /rev. pages 9 to 12 ® Low Noise, High Efficiency Gear Pump Elika Groups ELIKA2 Available displacement 3 3 from 7 cm /rev to 35 cm /rev. pages 13 to 24 ELIKA3 Available displacement 3 3 from 20.4 cm /rev to 87.1 cm /rev. pages 25 to 32 ELIKA4 Available displacement 3 3 from 86.5 cm /rev to 199.8 cm /rev. pages 33 to 37 www.jbj.co.uk/ELIKA_gearpumps.html #DriveLineHarmony ELIKA MULTIPLE PUMPS Identical models from the group 2, group 3 and group 4 families can be combined in double or triple configurations. pages 34 to 52 www.jbj.co.uk/elika-specs »
GHP2 ELIKA ELI2 40 45 50 55 60 65 70 75 80 1000 1500 2000 2500 3000 [rpm] [dBA] ® 3 ELI2 is the first in the ELIKA series and includes pumps with displacement from 7 to 35 cm / rev; perfectly interchangeable with the standard gear pumps ALP2 and GHP2 series. The maximum operating pressures are similar to those of GHP2 series and extend up to 300 bar. The helical gear ensures the continuity of flow despite the low number of teeth. The low number of teeth reduces the fundamental frequencies of the pump noise, reducing the noise level by an average of 15 dBA compared with a conventional external gear pump. ® The particular shape of the patented Elika profile eliminates the phenomenon of air encapsulation typical of normal gear pumps, curing the source of the main cause of noise and vibrations. Axial forces induced by the helical teeth are optimally balanced in all operating conditions by the axial compensation system integrated in the pump cover. Specific compensation areas in the flange and cover, insulated by special gaskets reinforced with anti-extrusion, allow for free axial and radial movement of the bushings, which is proportional to pump operating pressure. In this way, internal leakage is dramatically reduced, ensuring very good volumetric and mechanical pump performances, as well as proper lubrication of pump’s moving parts. Back and front plates are of anodized aluminum keeping the unit of low weight but up to the ® pressure generated. ELIKA pumps are available in both uni-directional clockwise or counter clockwise rotation. ® Low Noise, High Efficiency Gear Pump Elika Series 2 Noise pump comparison [dBA] Marzocchi GHP2 ELIKA ELI 3 2, same displacement 17.8 cm /rev. Efficiency pump comparison [%] Marzocchi GHP2 ELIKA ELI 3 2, same displacement 17.8 cm /rev. 1500 rpm Vol. Ef f . ELIKA Vol. Ef f . GHP Mech. Ef f . ELIKA Mech. Ef f . GHP www.jbj.co.uk/ELIKA_gearpumps.html #DriveLineHarmony 100 98 96 94 92 90 88 0 50 100 150 200 250 300 [bar] Average Efficiency[%]
100 150 200 250 300 350 400 1 10 100 1,000 10,000 0 500 1,000 1,500 2,000 2,500 3,000 3,500 4,000 4,500 75 80 85 90 95 100 0 200 400 600 800 1000 1200 1400 rpm Vol. Eff. [%] GHP2 ELI2 [rpm] [cSt] [bar] ® The particular shape of the Elika profile patented by Marzocchi Pompe, eliminates the phenomenon of air encapsulation typical of normal gear pumps, deleting the source of themain cause of noise and vibrations. The structure of the pump minimizes the internal leakage, maximizing the volumetric efficiency under all conditions. ® This feature makes the Elika pump suitable for work operations with low speed and ® high pressure. The internal leakage, virtually eliminated in the Elika range of pumps, laminating to outlet from the inlet, overheat the pump components in other pumps under similar conditions. ® Comparing the characteristics of the Elika with other types of volumetric pumps, it can be seen that they have exceptional operational qualities; the rotation speed, work pressure and viscosity range. Back and front plates are of anodized aluminum keeping the unit of lowweight but up to the pressure generated. ® Low Noise, High Efficiency Gear Pump Elika Series 2 Comparison of volumetric efficiency at low rotation speed: Marzocchi GHP 2 3 ELIKA ELI 2 , displacement 17.8 cm /rev; P = 200 bar. External gear pump & dual flank Piston pump Internal gear pump Vane pump Screw pump ® ELIKA pump comparison between the different fields of use of different kinds of volumetric pumps. 50 0 Work Viscosity Range Work Pressure Range Work Speed Range www.jbj.co.uk/ELIKA_gearpumps.html #DriveLineHarmony
ELIKA ELI 2 ELIKA ELI 2 + 2 ELIKA ELI 3 ELIKA ELI 3 + 2 ELIKA ELI 3 + 3 ELIKA ELI 4 ELIKA ELI 4 + 2 ELIKA ELI 4 + 3 ELIKA ELI 4 + 4 SINGLE SINGLE FRONT FRONT REAR REAR FRONT REAR SINGLE FRONT REAR FRONT REAR REAR FRONT ELI2 – 7 to 35 cc ELI3 – 20 to 87 cc ELI4 – 86 to 200 cc 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 3 cm /rev ® Low Noise, High Efficiency Gear Pump Elika Range Displacement Overview Elika displacement overview ELIKA ELI1P - ELIK1 SINGLE ELI1 – 2.1 to 8.1 cc Medical Equipment New Energy Sources Plastic Injection Moulding Machines Machine Tools and Testing Equipment Industrial Sector Material Handling Municipal and Sweeping Machines Presses & Waste Compactors Lifting Platforms Automotive Sector and Microhydraulics www.jbj.co.uk/ELIKA_gearpumps.html #DriveLineHarmony
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony
Extensive range and very high performance of these pumps integrated in to micro power packs make them ideal for many applications from aerospace to marine, medical to automotive. 0.25 - 0.5 Series Micro Gear Pumps High production rates, performance consistency and absolute reliability ensure this a benchmark product for the hydraulic power pack market. 1P Series Gear Pumps This product range includes pumps of displacements (up to 200cc/rev) in a full aluminium configuration, able to withstand medium to high pressures and using different versions of flanges (European, German and SAE), porting and shafts. Mono-directional as well as reversible. ALP Series Gear Pumps The GHP series offer identical configurations to theALP series and guarantees extreme reliability in very high pressure applications. Ideal for mobile applications from agricultural to construction machines as the cast iron allows more flange, cover and port options. GHP Series Gear Pumps ® ELIKA The low noise, low pulsation helical gear pump. Groups 1, 2, 3, 4 and multiple pumps. Reduces the noise level by up to 20 dBA. ALM Series Gear Motors For medium to high pressure rates the ALM series is ideal for mobile and industrial sectors. Mono-directional and bi-directional with internal and external drain available. GHM Series Gear Motors The GHM series offer identical configurations to the ALM series but more robust thanks to the cast iron front flange and rear cover. ALPC/GHPC Series Short Multiple Gear Pumps For reduced axial layout. Available with both flanges and covers in aluminium or cast iron. Ideal pump for applications which require a fast approach and/or return of the actuator at low loads and slow motion of the actuator at high loads. e.g. log splitters, compactors & presses. Volumetric andmechanical efficiencies as well as low noise levels are further benefits of this range. High/Low 2-Pass Gear Pumps Modularity and flexibility are the characteristics of these pumps. They allow the assembly of pump modules of the ALP and GHP (from 0.25 to 4) enabling solutions to a wide range of application requirements. ALP/GHP Series Multiple Modular Gear Pumps www.jbj.co.uk/gear-pumps.html
External gear pumps are the most popular pumps used in modern hydraulic systems. They feature versatility, strength and long life. Their simple construction ensures cost effective purchasing and service. Thanks to these basic concepts, coupled with ever improving product design and features, result in a quality product manufactured to the very highest standards. Due to the many years of research and experience, accurate material selection, rigid production process and rigorous testing on all aspects of the product range, enables Marzocchi gear pumps to operate under extreme working conditions and transmit high hydraulic power. In addition Marzocchi pumps are produced with good mechanical and hydraulic efficiency, low noise level and their compact dimensions give a low weight too power ratio. A gear pump usually consists of a gear pair supported by two aluminium bushes for groups 0.25, 0.5 and 1P, or bushes with plain bearings coated with anti-friction material for groups 1, 2, 3 and 4, a body, a securing flange and a cover. Shaft of the driving gear projecting beyond the flange mounts a twin-lip seal ring (the inner lip being a seal, the outer lip being a dust seal) for groups 0.25, 0.5 and 1P, or two opposed single-lip seal rings (the outer being a dust seal) for groups 1, 2, 3 and 4. Pump body, flange and cover are made of special high-resistant aluminium alloys for minimized deformation even when subject to high pressure, be it continuous or intermittent or peak pressure. The body is profiled by means of extrusion, whereas flange and cover are obtained by means of die-casting (gravity die-casting for some models). Gears are made of special steel. Their manufacturing process includes case-hardening and quench hardening. The gears are ground and fine finished so as to have a high degree of surface finishing. Proper tooth profile design and geometric proportions ensure low pulsation levels and low noise levels during pump operation. Bushes are made of special low-friction and high-resistant aluminium alloy and manufactured from die-casting. Special compensation zones onto flange and cover, insulated by special seals with anti-extrusion rings, allow fully free axial and radial movement to the bushes, which is proportional to pump operating pressure. In this way, internal leakage is dramatically reduced, thus ensuring very high pump performance (both in terms of flow and overall) and proper lubrication to the moving pump parts. Gear Pump Basic Design - simple construction, long and useful life. Basic pump parts 1 - Drive gear 2 - Driven gear 3 - Bushings 4 - Body 5 - Flange 6 - Cover 7 - Rotary shaft seal 8 - Compensation seals 9 - Anti-extrusion seals 10 - Circlip
An experienced and dedicated team of technical sales engineers are on hand to work with customers and deliver results. The markets where jbj operate are tough and time sensitive. In such circumstances customers need reliable solution partners, people who are conscious of deadlines, innovative in design and always willing to seek the best solution for the customers' needs. On all counts, jbj Techniques Limited deliver. From specification, through technical advice, manufacture and support, together with our extensive product database, jbj Techniques provide a comprehensive and valued service to the power transmission and hydraulic industries. jbj Techniques Ltd provide a diverse range of mechanical drive & transmission solutions to industrial markets including design engineering, product supply and after sales service. www.jbj.co.uk/Marzocchigearpumps.html integrated valves and mounting arrangements ALP/GHP . . . . VP-LS: Load sensing pump with priority valve. ALM . . . . VN - VM: Motors with anti-cavitation valves and relief valve. ALM . . . . VE: Motor with proportional relief valve. ALP/GHP . . . . T: Pumps with support bearing for high side/radial loads. ALP . . . . VM: Pump with integrated relief valve. ALM/GHM . . . . T: Motors with support bearings for high side/radial loads.
0.25 - 0.5 U0.25 -U 0.5 AC - 9 Nm G - 18 Nm 1P C - 9 Nm G - 9 Nm K1P - EK1P C - 26 Nm AS - 29 Nm G - 21 Nm ALP1 - GHP1 T0 - 100 Nm C0 - 55 Nm G0 - 45 Nm 1BK4 21 Nm 1BK7 20 Nm ALP1A - GHP1A C1 - 60 Nm S1 - 100 Nm ALP1AQ - GHP1AQ C2 - 100 Nm S2 - 95 Nm G1 - 45 Nm See specific catalogue for further details or contact jbj Techniques Ltd technical office, telephone: 01737 767493 or email: info@jbj.co.uk
GHP1A2 C3 - 120 Nm S3 - 145 Nm ALP2BK2 - GHP2BK2 ALP2BK4 - GHP2BK4 T2 - 180 Nm S4 - 140 Nm ALP2BK7 - GHP2BK7 G0 - 100 Nm ALP2 - GHP2 T0 - 200 Nm C0 - 135 Nm S0 - 140 Nm ALP2A - GHP2A C1 - 140 Nm S1 - 185 Nm C2 - 160 Nm S2 - 200 Nm ALP2BK1 - GHP2BK1 T1 - 180 Nm S3 - 140 Nm GHP2A3 C3 - 140 Nm S5 - 140 Nm See specific catalogue for further details or contact jbj Techniques Ltd technical office, telephone: 01737 767493 or email: info@jbj.co.uk
See specific catalogue for further details or contact jbj Techniques Ltd technical office, telephone: 01737 767493 or email: info@jbj.co.uk ALP4 T0 - 550 Nm ALP3 - GHP3 T0 - 300 Nm C0 - 350 Nm ALP3A - GHP3A C1 - 450 Nm S1 - 600 Nm S2 - 650 Nm GHP3.5 GHP3BK1 T1 - 300 Nm T2 - 400 Nm GHP3A2 C1 - 450 Nm S1 - 600 Nm ALP4E ALP4A C0 - 450 Nm S1 - 900 Nm E D A FG, FC, FA, FM
® patented Elika profile is everything 01737 767493 info@jbj.co.uk www.jbj.co.uk - registered in England No: 1185469 - jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/E requirements The new range of cast iron gear pumps and motors fully represents Marzocchi Pompe S.p.A.'s determination to further expand the largest available selection of external gear pumps and motors in order to deliver to the Customer everything they need and support them in applications requiring very high pressures, optimal performance and endurance . . . Highworking pressures » High efficiency at high temperatures » High speeds » an excellence in engineering You Tube THE NEW FULL CAST IRON RANGE BY MARZOCCHI POMPE www.jbj.co.uk/cast-iron-gear-pumps-and-motors.html www.jbj.co.uk/cast-iron-gear-pumps-and-motors.html #DriveLineHarmony IV
Getting the most out of your machinery often depends on close integration between all components. An organisation that manufactures and integrates all the diverse components of a drivetrain provides the experience to help you select the best component combination for your application. jbj Techniques’ in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The following examples are a simplistic view of how jbj Techniques assists customers. Hydraulic Adaptors Designed primarily to allow the close coupling of hydraulic pumps to a variety of prime movers, such as diesel / petrol engines, electric, air or hydraulic motors, they can also be used in the connection from prime mover to alternative driven parts i.e. gear boxes, generators, water or vacuum pumps etc. An additional range of engine front PTO adaptors, which provide additional connection between the engine pulley and the driven part are also available. The kit comprises of a and flexible bellhousing drive that are fully machined to suit the coupling driving and driven components. These can be to suit either shaft to shaft, flange (flywheel) to shaft or even flange to flange connections. Getting the most out of your equipment will demand close integration between all components. In specifying jbj Techniques as your preferred supplier, you will have selected a company with the experience to specify, manufacture and integrate all of the diverse components that will ensure the best component combination for your application. jbj's in house design team and manufacturing facility provide tailored solutions for your applications at competitive pricing and on-time deliveries. Pump shaft alignment is key to preventing unnecessary wear and damage to the pump shaft seal and bearing. Improper alignment may lead to premature pump failure. Also to be considered are unwanted torsional resonant frequencies in the system which can quickly cause damage to components in the drivetrain and reduce system life and performance. Improper pump installation can lead to premature failure, increased maintenance costs and reduced production levels of final product. jbj Techniques can advise on the correct installation of into Industrial / hydraulic pumps mobile / marine / machine tool / agricultural / offshore industries and can specify complete driveline systems from their extensive range of components which are available from stock or manufactured to order, albeit simple or complex, standard or bespoke. Electric Motor – Hydraulic Pump Adaptors (safe area) jbj Techniques Limited offer the most comprehensive range of in Europe. bellhousings Designed to connect electric motors with frame size IEC D56 - D400 (0.06kW – 750kW) and can be compatible with electric motor 'B5' or 'B14' flange configurations. Accompanying the metric frame units above is a complete range of mountings to suit Nema and imperial frame motors with 'C' face or 'D' flange fitments. With fully machined , torsionally flexible couplings or available, jbj ensure torsionally rigid couplings the most suitable combination is selected for the application in hand. As an example spider couplings are available in various materials including aluminium, grey cast iron, nodular iron, steel and stainless steels and can be finish machined with parallel, taper or splined bores to DIN, SAE, ANSI or ISO standards. Bellhousings can be manufactured in aluminium or cast iron material as standard, however, units can be produced in a variety of exotic materials on request. The aluminium product range is produced in either monoblock or composite formats giving great flexibility in design and allows for early delivery time, often with same or next day delivery possibilities. For applications where low noise levels are a quality products for mechanical & fluid power #DriveLineHarmony www.jbj.co.uk an excellence in engineering
ensuring a continuing high quality service in which customers can have complete confidence. “ “ requirement then a complete range of antivibration and noise reduction components add to the range. Electric motor – Hydraulic Pump Adaptors (hazardous area) Designed to meet the exacting safety standards of the offshore and chemical process industries, jbj Techniques produce certificated to adaptor kits Directive 2014/34/EU II2GD-IM2-TX -50 C< Service Temp < +105 C. Harmonised standards BS EN 1127:1, BS EN 13463:1, BS EN13463:5, BS EN 50303, BS EN 1834-1,BS EN 1834-3. Generally manufactured in Cast or Nodular iron, bellhousings can be produced in steel, stainless steel or alternative exotic materials on customer request. Couplings supplied for these applications are the jbj Techniques 'JXL' pin and bush range which provide an anti-static and flameproof drive which meet zone 1 area requirements, conforming to all of the above standards. Also available are spider and gear couplings which are certified to zone 2 standards. (Contact jbj Techniques for details). An important development of equipment for use within hazardous areas is the wet mount series of bellhousings. Commissioned to research and develop a product that would control the high temperature generated by a piston pump shaft seal when working within cycling applications. A little considered issue is the frictional heat generated at the shaft seal when the application requires the pump to cycle between different pressures causing the seal temperature to increase. This process will often take the seal temperature out and above the levels required by the relevant ATEX standards requirement. This specially designed assembly allows a pumped cooling flow to be passed over the seal face and through an auxiliary cooler, this in turn reduces the seal face temperature which can be maintained at an acceptable level. With a vast array of components to select from, jbj are well placed to provide all required components to support the required cooling system. Diesel Engine – Hydraulic Pump Adaptors A complete range of bellhousing and couplings exist for the connection of a diesel engine flywheel to a specified driven component, be it an oil hydraulic pump, water pump, generator or similar device. With the bellhousing available in various materials to suit all application areas. With a standard range to connect Diesel engines with SAE dimensions from SAE '6' to SAE '0' jbj are well placed to satisfy the majority of customer requirements. Couplings to complete the assembly are available in either torsionally flexible or torsionally rigid design ad can be supplied to suit SAE flywheel dimensions from SAE 6.5” to SAE 18”. For hydraulic pumps to be mounted to engines that do not conform to SAE dimensions, we offer a full range of assembly parts, some of which (but not all) are shown here » for diesel engines All bellhousings within this range can be finished machined to accept any, piston, vane or gear pump interfaces requested by customer. As with the electric motor range of product jbj offer complete solutions for ATEX environments, using our well proven 'JXL' coupling range which has standard design to connect to the engine flywheel. Directive 2014/34/EU II2GD-IM2-TX -50°C ≤ Service Temp ≤ +105°C. Harmonised Standards: BS EN 1127:1 BS EN 13463:1 BS EN 13463:5 BS EN 50303. Petrol Engine – Hydraulic Pump Adaptors Petrol engine adaptors have been developed for use with industrial petrol engines. Design exists to suit Honda, Briggs and Stratton, Kawasaki, Kubota, Hatz, Mag, Robin, Suzuki, Winsconsin, to name but a few, all adaptors can be finished to accept most hydraulic pumps. Adaptors to suit engine crankshaft drives and for vertical mounting are available on request. #DriveLineHarmony www.jbj.co.ukl to Large Combinations Small Individual Components
to Large Combinations from Small Individual Components ensuring a continuing high quality service in which customers can have complete confidence. “ “ # Driveline jbj Techniques is a specialist supplier of high-quality products for the mechanical power transmission and fluid power sectors. The company offers a high level of in-house expertise plus a huge selection of products to meet a very broad range of customer applications. From specification, through technical advice and manufacture to after-sales support, jbj Techniques provides a comprehensive and valued service to the power transmission and hydraulics industries. The company fields a UK-wide team of technical sales engineers to ensure that the business is close to its customers, and it enjoys excellent associations with European manufacturers, acting as sole UK distributor in many cases. jbj’s team is recognised for its expertise in the selection and configuration of hydraulic and mechanical transmission systems. Able to draw on an that extensive product range provides the building blocks for bespoke systems both large and small, the in-house design team offers a complete service, ranging from an assessment of customer requirements to full technical backup, including product specification, CAD based system design, system build and certification. Moreover customers can take advantage of jbj’s own machine-shop facilities and skilled engineers guarantee to quality and control costs. jbj Techniques provides one of the widest ranges of couplings available within the UK; mechanical power transmission couplings for a vast range of applications. Ranging from miniature couplings, all steel gear couplings, flexible spider couplings, shaft couplings, torque limiting couplings, disc and grid type couplings, ATEX compliant and shaft locking devices. Magnetic couplings for power transmission between hermetically sealed areas. However as extensive as the selection is, couplings make up a fraction of jbj’s portfolio. As power transmission specialists the company stock and provide gearboxes, clutches, pumps, hydraulic motors, flow meters, fluid power accessories including: cooling & heat exchange products, reservoirs, pipe flanges, seals and level indicators, as well as a variety of bellhousings and engine adaptors, to name just a few of the product categories. jbj Techniques Limited is proud of it’s relationship and reputation with customers and suppliers. The core client base is stable and loyal, which is testament to the quality of service provided by the company. A similar relationship exists with suppliers, ensuring a continuing high quality service in which customers can have complete confidence. Dampers Engine Adaptor Kits Hydraulic Adaptors Torque Limiting Couplings Tyre Couplings Anti-static/Flameproof Couplings Torsionally Rigid Couplings Torsionally Flexible Couplings Bellhousings Permanent Magnetic Couplings Torsional Couplings
ne Harmony comprehensive range of components www.jbj.co.uk an excellence in engineering 01737 767493 info@jbj.co.uk www.jbj.co.uk - registered in England No: 1185469 - jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/E requirements Screw Pumps Pneumatic Motors & Starters Gear Pumps/Motors Axial & Radial Piston Motors Vane Pumps LSHT Motors/Geared Motors Splitter Gearboxes Planetary Gearboxes BDS Clutches BD Clutches & Gearboxes Oil Bath Clutches Flow Dividers Tanks/Accessories Fluid Level Indicators Flanges Mini Power Packs Coolers Pressure Intensifiers You Tube
