Gear Pumps Basic Design BASIC PUMP PARTS 1 - Drive Gear 2 - Driven gear 3 - Bushings 4 - Body 5 - Flange 6 - Cover 7 - Rotary shaft seal 8 - Compensation seals 9 - Anti-extrusion seals - stop Ring Marzocchi Pompe has further developed its own range of products with a new series of pumps named GHP where groups named GHP1, GHP2 and GHP3 suitable for the widest range of application, both in the industrial and themobile sector. Bushings are made of special low-friction and hi-resistant aluminum alloy and manufactured from die-casting. Besides they are equipped with antifriction DU bearings. Special compensation zones onto bushings, insulated by special preformed seals with anti-extrusion ring, allow fully free axial and radial movement to the bushes, which is proportional to pump operating pressure. In this way, internal dripping is dramatically reduced, thus ensuring very good pump performance (both in terms of volume and in general) and proper lubrication of pumpmoving parts. The body of the pump is made of special hi-resistant aluminum alloy obtained through extrusion process, while flange and cover are made out of spheroidal cast iron; this in order to ensure minimized deformation even when subject to high pressure, be it continuous or intermittent or peak pressure. Gears are made of special steel. Their manufacturing process includes case-hardening and quench hardening. Then gears are ground and fine finished so to have a high degree of surface finishing. Proper tooth profile design and geometric proportions ensure low pulsation levels and low noise levels during pump operation. External gear pumps are the most popular pumps used in modern hydraulic systems. They feature versatility, strength and long useful life. Their simple construction ensures limited purchase costs and servicing. Thanks to these basic concepts, together with ever improving product design and features, research based on many years of experience, accuracy in material selection, production process followed in great detail and tests onmass-produced parts, our gear pumps have reached top quality standards. For this reason, our products can work under heavy operating conditions and transmit high hydraulic power. Furthermore, these gear pumps feature good hydraulic, mechanical and volumetric efficiency, low noise level and, last but not least, compact dimensions. Generally these gear pumps usually consist of a gear pair supported by two aluminum bushes, a body, a securing flange and a cover. Shaft of the driving gear projecting beyond the flange mounts a twin-lip seal ring (the inner lip being a seal and the outer being a dust seal). An elastic securing ring secures the ring in place. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 10 6 2 7 5 8 9 3 1 4 8 9 6 3 10

4.5 6.4 7.0 9.6 11.5 14.1 16.0 28.2 GHP2 Series 23.7 21.1 17.9 20 22 26 33 39 44 52 78 87 GHP3 Series 71 61 3 Displacement (cm /rev) 1.4 2.1 2.8 3.5 4.1 5.2 6.2 7.6 9.3 11.0 GHP1 Series 13.8 35.2 Gear Pumps GHP Series Product Range The following items are also available: » reversibile pumps (field ROTATION "R") »pumps with independent driving systems (field OPTION "T" or "RA"). GHPseries hydraulic gear pumps Marzocchi GHP series gear pumps are produced in three different groups. Within each of them, the different displacements (between 1.4 and 87 cm3/rev) are obtained using different width of the gears. Different flanges, shafts, inlet and pressure ports are available. 7 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Contact jbj Techniques technical office for assistance in selection of correct pump for your application, telephone: +44 (0)1737 767493, email: info@jbj.co.uk Range between -10°C and +120°C. In the range between -10°C and +80°C maximum pressures P1, P2 and P3 are possible as per the product table; beside that P1 should not be exceeded. "VV"Version suitable for fluid at high temperatures. "ST"Version suitable for fluid at high or low temperature. Special Versions For special uses are also available: "V"Version suitable for fluid at high temperatures. Range between -10°C and +150°Cwithmaximumpressure 20 bar Range between -40°C and +120°C. In the range between -10 °C and +80°C maximum pressuresP1, P2 and P3 are possible as per the product table; beside that P1 should not be exceeded. "H"Version suitable for fluid at low temperature. Range between -40°C and +80°C. In the range between -10 °C and +80°C maximum pressures P1, P2 and P3 are possible as per the product table; beside that P1 should not be exceeded. “TR”Version suitable for inlet pressure up tomax. 6 bar absolute. The above descriptions are to be specified in the SEALfield of the ordering code.

Disconnect pump drain during startup to bleed air off the circuit. Start the system for a fewminutes and turn on all components; bleed air off the circuit to check its proper filling. Some general considerations should be made regarding the hydraulic system, in which the pump is to be fitted. Special attention should be given to hydraulic system design and assembly, especially to intake, delivery, return and drain pipes and position of system parts (valves, filters, tanks, heat exchangers and accumulators). It is essential for correct running, top performance and longer life of the GHP series hydraulic gear pumps to follow the installation and running information provided in this catalogue. Check for the direction of rotation of the pump to be consistent with the drive shaft one (in case of single rotation pump). InstallationNotes Protect drive shaft seal during pump painting. Check if contact area between seal ring and shaft is clean: dust could cause quicker wear and leakage. Proper safety devices and reliable instruments to avoid fluid turbulence and prevent air, water or foreign bodies from entering into the system are of major importance. It is also very important to equip the hydraulic systemwith a proper filtering unit. Remove all dirt, particles and all foreign bodies from flanges connecting inlet and delivery ports. Ensure that intake and return pipes ends are always below fluid level and as far fromeach other as possible. Before starting the systemon a continuous basis, we suggest to adopt some simple precautions. Install the pump below head if possible. Fill the pump with fluid, and turn it by hand. At first startup, set pressure limiting valves at min. value possible. Check for the proper alignment of pump shaft. It is necessary that the connection does not induce axial or radial loads. Avoid lower rotation speed thanmin. allowed with pressure higher than P1. Do not start the systemat low temperatures under load conditions or after long stops (always avoid or limit load starting for pump longer life). Check fluid level in the tank after loading all components. At last, gradually increase pressure, continuously check fluid and moving parts temperature, check rotation speed until you reach set operating values that shall be within the limits indicated in this catalogue. CleaningAnd Filtering The System It is widely known that most pump early failures are due to contaminated fluids. The extreme reduction of the tolerances required in the design of the pumps, and therefore their operation with minimum clearances, are heavily influenced by a fluid that is not perfectly clean. It is proved that particles circulating in the fluid act as abrasive agents, damaging the surfaces they touch and increasing the quantity of contaminant. Regular checks should be made for contamination of the oil. Preventive actions include: proper cleaning of the system during assembly, deburring, eliminating the welding scumand fluid filtering before filling up. Starting contamination level of system fluid should not exceed class 18/15 (ref. ISO 4406). Even fresh fluids might exceed this contamination level; therefore For this reason, ensure that system is perfectly clean during startup and keep it clean for its whole operating life. Gear Pumps GHP Series Installation and Running Information 8 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

Gear Pumps GHP Series Installation and Running Information 9 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony always pre-filter the fluid when filling up or topping up the system. Fit a proper tank; its capacity should be proportional to the volume displaced in one working minute. Fluid contamination levels should be monitored by use of correct filter types. Two parameters tell which filter is most suitable: absolute filtering power andb filtering ratio. Low absolute filtering power and highbfiltering ratio for small particles help ensuring good filtration. It is then very important to limit not only the size of particulate, but also the number of smaller particles that pass through the filter. It goes without saying that with an operating pressure increase and according to the system sophistication degree, filtering should becomemore andmore efficient. The filtering system shall always ensure contamination levels not exceeding the values indicated below: Pressure <140 bar 140 to 210 bar >210 bar NAS 1638 Class 10 9 8 ISO4406 Class 19/16 18/15 17/14 Ratiobx = 75 25-40 μm 12-15 μm 6 -12 μm It is recommended to use a filtering systemhaving absolute filtering capability of 5 μmor lower in the systems using sophisticated valve slaves. Hydraulic Fluids Group GHP1 allowed value (upon verification) 6 to 500 cSt Min. Speed (rpm) 800 700 500 recommended value 10 to 100 cSt Size 6 9 10 12 13 16 20 22 25 30 34 37 40 50 For the standardmodels, the temperature of the fluid should be between -10°C and +80°C. Min. Speed (rpm) 600 500 400 The versatility of the GHP series pumps is seen from the wide range of rotation speeds they can be subject to: maximum values are indicated in product tables and change according to themodel, whileminimum values are as follows: Min. Speed (rpm) 700 Group GHP2 Inlet Pressure Group GHP3 Min. Rotation Speed value allowed at startup <2000 cSt Fluid kinematic viscosity ranges are of following: Use specific mineral oil based hydraulic fluids of good anti-wear, anti-foaming (rapid deaeration), antioxidant, anti-corrosion and lubricating properties. Fluids should also comply with DIN 51525 and VDMA24317 standards and compliant with 11th stage of FZG test. Under standard working conditions, intake pipe pressure is lower than atmospheric pressure. The operating inlet pressure should range between 0.7 and 3 bars (absolute). If fluids other than the above mentioned type are used, please always indicate type of used fluid and operating conditions so that jbj Techniques technical office can advise of possible problems with compatibility or useful life of systemparts. Size 2 3 4 5 6 7 9 11 13 16 20 Size 30 33 40 50 60 66 80 94 110 120 135

Gear Pumps GHP Series Installation and Running Information 10 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Pressure diagramas a function of time. P1, P2 and P3 values can be attained only if systemdoes not go over the following rotation speeds: Pressure Definition Product tables show threemax. pressure levels (P1, P2 and P3) to which each pump can be used. P3 = peak max pressure. P1 = continuous max. pressure. P2 = intermittent max. pressure. P3 P2 P1 t (sec) Max. 20 sec. Max. 2 sec. p(bar) Intake line 0.5 to 1.66m/s Speed (rpm) 2500 2000 1500 Speed (rpm) 2000 1500 1000 Please contact jbj Techniques technical department, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 for system operating conditions other than indicated in the product tables. Group GHP2 Hydraulic systempipes should show no sudden changes of direction, sharp bends and sudden differences in cross-section. They should not be too long or out of proportion. Pipe cross-section should be sized so that fluid velocity does not exceed recommended values. It is advisable to carefully consider the possible diameter reduction of the inlet or outlet pipes fitted on flange fittings. Reference values are the following: Size 30 33 40 50 60 66 80 94 110 120 135 Return line 1.6 to 3m/s Size 2 3 4 5 6 7 9 11 13 16 20 Size 6 9 10 12 13 16 20 22 25 30 34 37 40 50 Group GHP3 Group GHP1 Speed (rpm) 3500 3000 2000 1500 Supply &Delivery Lines Delivery line 2 to 6m/s

Direction of Rotation The GHP series gear pumps are available as single directional and bi-directional. The direction of rotation is defined in the following way: looking at the front of the pump with the driver shaft positioned upward and sticking toward the observer, it will be a mono-directional right "D". GHP...D pump therefore with right. "D" rotation, if its rotation will be clockwise and therefore the inlet port will be on the left while the outlet port will be on the right. Vice-versa it will be a monodirectional left GHP...S therefore with left "S" rotation when looking at it from the same angle.. S = counter-clockwise rotation INPUT OUTPUT D = clockwise rotation INPUT OUTPUT R = reversible rotation The bi-directional GHP series pumps, "R" have both functional characteristics of the mono-directional motors with clockwise and counterclockwise rotation. Connect the pump to the motor using a mechanical power transmission coupling so that no radial and/or axial force is transmitted to the pump shaft during rotation, otherwise pump efficiency will dramatically drop due to early wear of inner moving parts. jbj Techniques have a wide range of suitable couplings to suit a wide range of applications and we can advise on which coupling depending on the circumstances of the application. Calculate the velocity (v) of a fluid in a pipe as follows: v =Q / 6 •A[m/s] Frequently Used Formulas Drive For further details contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 In case of axial and/or radial loads on themotor’s shaft T option is available for some GHP2models and RAoption is available for some GHP1 types. Fluid velocity A= inside area of pipe [cm²] Absorbed flow rate V = displacement [cm³/rotation] hvol = pump volumetric efficiency (take 0.95 as an indicative value for rotation speeds ranging between 1000 and 2000 rotations per minute) Calculate flow rate (Q) as follows: Absorbed torque Q= flow rate [litre/min] Q= V • n • 10 -3 / hvol [litre/min] n = rotation speed [rotations per minute] Calculate necessary torque (M) of a pump subject to pressure differential between inlet and delivery as follows: V = displacement [cm³/rotation] M= (V •Dp) / (62.8 • hhm) [Nm] Dp = pressure differential [bar] hhm= hydromechanical efficiency (take 0.80 as indicative value under cold conditions and 0.85 under working conditions). Gear Pumps GHP Series Installation and Running Information 11 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

Gear Pumps GHP Series Information 12 Once the pump flow rate has been selected, different flanges, shafts, inlet and outlet port position and type are available to suit most applications. In the product tables, the flow, shown at 1500 rpm, has been evaluated using a value of volumetric efficiency of 95%. All the drawings represent pumps with clockwise rotation. Reversing the direction of rotation also involves reversing of the suction side with the delivery side ports. The following diagrams show, for each single displacement, the typical required power as a function of rotation speed and pressure generated by the system and allow you to easily spot the product suitable for your application. Calculate hydraulic power (P), delivered by amotor subject to a pressure differential between input and output as follows: Dp = pressure differential [bar] Q= flow rate [litre/min.] Apump requires energy, just like any other hydraulic machine. Part of this power is given to the fluid to increase pressure required by the circuit, the remaining part is used to cure pump internal friction. Therefore, for proper pump operation, supplied torque shall be higher than theoretical torque. P= (Q •Dp) / (600 •htot) [kW] htot = total pump efficiency (hhm •hvol) Contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 for further details on efficiency. The proper values for flow rate, torque and supplied according to pressure differential, rotation speed and set test conditions, can be found on thePerformance Curvepages. These pumps are hydraulic machines converting mechanical power into hydraulic power. This section deals with rotary positive-displacement pumps. In this type of pump, a given volume of fluid flows from inlet to outlet at each shaft rotation (theoretical displacement). Pressure depends on delivery line resistance to fluid flow. As gear pumps only transfer fluid, they are subject to pressure generated by the circuit. Therefore, if system flow rate and motor rotation speed are known, it is easy to select the right pump displacement and its model. Absorbed power Values for hvol andhhm (and consequentlyhtot) depend on pressure differential between supply and delivery, rotation speed, fluid features (temperature and viscosity) and filtering degree. The diagram indicating flow rate variations according to speed and pressure, shows that not all the theoretically available fluid is transferred from inlet to outlet because of pump internal leakage. Leakage can be greatly reduced through pressure axial compensating systems (as described at the beginning of this catalogue) but never eliminated. Leakage increases as circuit pressure increases. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

D Type Rotation Size Ports* Seals* Options* omit A AQ Clockwise S Counter Clockwise GHP1 Drain** R Reversible Pump Standard Types GHP1A-D-2-S1 = clockwise rotation, 1.4 cc/rev, SAEA-A2 bolt flange, splined shaft 9T (S1), threaded ports, standard seals. Examples omit = European flange + shaft T0 + ports E + standard seals. AQ= flangeAQ+ shaft C2 + ports FA+ standard seals. GHP1-D-2-FG-V = clockwise rotation, 1.4 cc/rev, European flange,1:8 tapered shaft, threaded ports (FG), high temperature seals (V). A= flangeA+ shaft C1 + ports FA+ standard seals. GHP1-D-2 = clockwise rotation, 1.4 cc/rev, European flange,1:8 tapered shaft, flanged ports E type, standard seals. The product data sheets show our standard model types. The synoptic tables for flanges, shafts and ports show all the possible configurations. For further details about the availability of each configuration please contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 Ordering Code Shaft* E1 = external drain G1/4 H E2 = external drain ⁹⁄ -18 UNF*** Options E0 = internal drain (***) = "E2" drain port is machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). omit (T range = -10°C + 80°C) Drain TR (**) = only for R rotation. (*) = to be specified if different from standard “pump type”. RA Thread depth 12.7 mm. Seals ... ... V ... 2 3 4 5 6 7 9 11 13 16 20 Gear Pumps GHP1 Series 13 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony A2 www.jbj.co.uk/hydraulic-adaptors.html The package consists of a bellhousing and flexible drive coupling that are fully machined to suit the pump and any driving interface; diesel or petrol engine, electric or hydraulic motor. jbj's in-house design teamandmanufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. A range of composite bellhousings to accommodate electric motor flanges from 300 mm diameter to 800 mm diameter. See pages 40 to 44 of the Pump Drive Components technical specification catalogue. Acollection of different ways of connecting hydraulic pumps andmotors to various driver devices. allow close coupling of hydraulic pumps directly to the flywheel / flywheel housing of diesel engines, electric and hydraulic motors.

Gear Pumps GHP1 Series Standard ports: M6 threads depth 13 mm. Accessories supplied with the standard pump: woodruff key (code 522054), M10x1 hexagonal nut (code 523015), washer (code 523004). 14 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony OUTLET INLET 3 cm /rev litres/mim bar bar bar rpm mm mm GHP1-D-9 6.2 8.8 260 275 290 3800 47 93 GHP1-D-6 4.1 5.9 270 290 310 4000 44 87 1500 rev/min P P P Speed L M I 2 3 GHP1-D-7 5.2 7.4 260 275 290 4000 45.5 90 GHP1-D-4 2.8 3,9 270 290 310 5000 42 83 GHP1-D-11 7.6 10.8 230 245 260 3200 49 97 GHP1-D-16 11.0 15.7 200 215 230 2200 54 107 Type Displacement Flow at Maximum Pressure Maximum Dimensions GHP1-D-13 9.3 13.3 210 225 240 2600 51.5 102 GHP1-D-3 2.1 2,9 270 290 310 6000 41 81 GHP1-D-20 13.8 19.7 180 195 210 1800 58 115 GHP1-D-5 3.5 4.9 270 290 310 5000 43 85 GHP1-D-2 1.4 2.0 270 290 310 6000 40 79

Gear Pumps GHP1A Series Accessories supplied with the standard motor: key (code 522070). Mounting flange 50-2 (A-A) in compliance with SAE J744c. Standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). 15 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony OUTLET INLET GHP1A-D-2 1.4 2.0 270 290 310 6000 42 81 ⁹⁄ -18 UNF ³⁄ -16 UNF 1500 rev/min P P P Speed L M d D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm Type Displacement Flow at Maximum Pressure Maximum Dimensions GHP1A-D-3 2.1 2.9 270 290 310 6000 43 83 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A-D-5 3.5 4.9 270 290 310 5000 45 87 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A-D-6 4.1 5.9 270 290 310 4000 46 89 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A-D-7 5.2 7.4 260 275 290 3500 47.5 92 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A-D-9 6.2 8.8 260 275 290 3000 49 95 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A-D-4 2.8 3.9 270 290 310 5000 44 85 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A-D-11 7.6 10.8 230 245 260 3500 51 99 ³⁄ -16 UNF ⁷⁄ -14 UNF GHP1A-D-13 9.3 13.3 210 225 240 3000 53.5 104 ³⁄ -16 UNF ⁷⁄ -14 UNF GHP1A-D-20 13.8 19.7 180 195 210 2000 60 117 ³⁄ -16 UNF ⁷⁄ -14 UNF GHP1A-D-16 11.0 15.7 200 215 230 2500 56 109 ³⁄ -16 UNF ⁷⁄ -14 UNF

Gear Pumps GHP1AQ Series Accessories supplied with the standard motor: key (code 522223). "D" and “d” standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). 16 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony OUTLET INLET Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed L M d D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm GHP1AQ-D-2 1.4 2.0 270 290 310 6000 59 98 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1AQ-D-3 2.1 2.9 270 290 310 6000 60 100 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1AQ-D-4 2.8 3.9 270 290 310 5000 61 102 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1AQ-D-6 4.1 5.9 270 290 310 4000 63 106 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1AQ-D-9 6.2 8.8 260 275 290 3000 66 112 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1AQ-D-13 9.3 13.3 210 225 240 3000 70.5 121 ³⁄ -16 UNF ⁷⁄ -14 UNF GHP1AQ-D-16 11.0 15.7 200 215 230 2500 73 126 ³⁄ -16 UNF ⁷⁄ -14 UNF GHP1AQ-D-7 5.2 7.4 260 275 290 3500 64.5 109 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1AQ-D-20 13.8 19.7 180 195 210 2000 77 134 ³⁄ -16 UNF ⁷⁄ -14 UNF GHP1AQ-D-5 3.5 4.9 270 290 310 5000 62 104 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1AQ-D-11 7.6 10.8 230 245 260 3500 68 116 ³⁄ -16 UNF ⁷⁄ -14 UNF

Gear Pumps GHP1A2 Series Accessories supplied with the standard motor: key (code 522067). Mounting flange 82-2 (A) in compliance with SAE J744c. "D" and “d” standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). 17 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony GHP1A2-D-4 2.8 3.9 250 270 290 5000 43 84 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A2-D-6 4.1 5.9 250 270 290 4000 45 88 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A2-D-16 11.0 15.7 170 185 200 2500 55 108 ³⁄ -16 UNF ⁷⁄ -14 UNF Type Displacement Flow at Maximum Pressure Maximum Dimensions GHP1A2-D-3 2.1 2.9 250 270 290 6000 42 82 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A2-D-2 1.4 2.0 250 270 290 6000 41 80 ⁹⁄ -18 UNF ³⁄ -16 UNF 1500 rev/min P P P Speed L M d D I 2 3 GHP1A2-D-7 5.2 7.4 230 245 260 3500 46.5 91 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A2-D-9 6.2 8.8 230 245 260 3000 48 94 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A2-D-20 13.8 19.7 150 165 180 2000 59 116 ³⁄ -16 UNF ⁷⁄ -14 UNF 3 cm /rev litres/mim bar bar bar rpm mm mm GHP1A2-D-5 3.5 4.9 250 270 290 5000 44 86 ⁹⁄ -18 UNF ³⁄ -16 UNF GHP1A2-D-11 7.6 10.8 200 215 230 3500 50 98 ³⁄ -16 UNF ⁷⁄ -14 UNF GHP1A2-D-13 9.3 13.3 180 95 210 3000 52.5 103 ³⁄ -16 UNF ⁷⁄ -14 UNF OUTLET INLET

T0 C0 A C1 S1 AQ C2 S2 G1 G0 Max Torque 100 Nm Max Torque 55 Nm Max Torque 60 Nm Max Torque 100 Nm Max Torque 45 Nm Max Torque 100 Nm Max Torque 95 Nm Max Torque 45 Nm Flanges Shafts Gear Pumps Flanges & Shafts GHP1 Series 18 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony jbj's in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. www.jbj.co.uk/hydraulicadaptors.html A collection of different ways of connecting hydraulic pumps and motors to various driver devices. A2 C3 S3 Coppia Max Max Torque 120 Nm Coppia Max Max Torque 145 Nm allow close coupling of hydraulic pumps directly to the flywheel / flywheel housing of diesel engines, electric and hydraulic motors.

GHP1…2 to GHP1…9 ³⁄ -16 UNF ⁹⁄ -18 UNF GHP1…11 to GHP1…20 ⁷⁄ -14 UNF ³⁄ -16 UNF GHP1…2 to GHP1…20 Rc¹⁄ Rc¹⁄ E FG FC FA GHP1…2 to GHP1…20 30 13 M6 30 13 M6 GHP1…2 to GHP1…5 G¹⁄ G³⁄ GHP1…6 to GHP1…20 G¹⁄ G¹⁄ Tightening torques of the fittings screws are specified on pages 56 and 57 (accessories section). Ports Gear Pumps Ports GHP1 Series 19 Tightening torques for Rc¹⁄ fitting: 50 Nm. Please check with the fittings suppliers. Tightening torques for 9/16-18 UNF fitting: 30 Nm. Tightening torques for 3/4-16 UNF fitting: 60 Nm. Tightening torques for 7/8-14 UNF fitting: 70 Nm. Please check with the fittings suppliers. Tightening torques for G¹⁄ fitting: 50 Nm. Tightening torques for G³⁄ fitting: 35 Nm. Please check with the fittings suppliers. Inlet Outlet Type A B C A B C Inlet Type A A Outlet Inlet Type Outlet A A Inlet Type Outlet A A www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

2 3 4 25-300 bar 5 6 25-280 bar 7 9 25-270 bar 11 25-230 bar 13 25-190 bar 16 25-170 bar 20 25-150 bar 20 Gear Pumps Performance Curves GHP1 Series www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

21 Gear Pumps Performance Curves GHP1 Series Absorbed power P [kW]. Absorbed torque M [Nm]. Drive speed n [rpm] www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

22 Gear Pumps Performance Curves GHP1 Series Absorbed power P [kW]. Absorbed torque M [Nm]. Drive speed n [rpm] www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

23 Gear Pumps Performance Curves GHP1 Series Absorbed power P [kW]. Absorbed torque M [Nm]. Drive speed n [rpm] www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

50 D Type Rotation Size Ports* Seals* Options* omit A A3 BK1 Clockwise S Counter Clockwise GHM2 Drain** R* Reversible GHM2A-R-6-OR-E2 = Reversible motor, 4.5 cc/rev, SAE A 2 bolt flange, cylindrical shaft C1, threaded ports FA, standard seal, OR seal on pilot, external drain (E2). BK1 = flange BK1 + shaft T1+ ports D + standard seals. omit = European flange + shaft T0 + ports E + standard seals. A= flangeA+ shaft C1 + ports FA+ standard seals. GHP2A-D-6-KA= Clockwise rotation, 4.5 cc/rev, SAEA2 bolt flange, cylindrical shaft, standard seals, UNF threaded rear ports (KA). GHP2-R-13-E1 = Reversiblemotor, 9.6 cc/rev, European flange, 1:8 tapered shaft , flanged ports E type, standard seals, external drain (E1). Examples The product data sheets show our standard model types. The synoptic tables for flanges, shafts and ports show all the possible configurations. For further details about the availability of each configuration please contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 Pump Standard Types GHP2BK2-D-6-E = Clockwise rotation, 4.5 cc/rev, German square flange, 1:5 tapered shaft , European flanged ports (E), standard seals. BK4 = flange BK4 + shaft T2 + ports D + standard seals. GHP2-D-6 = Clockwise rotation, 4.5 cc/rev, European flange,1:8 tapered shaft, flanged ports E type, standard seals. A3 = flangeA3 + shaft C3 + ports FA+ standard seals. BK2 = flange BK2 + shaft T2 + ports D + standard seals. BK7 = flange BK7 + shaft G0 + ports D + standard seals. Gear Pumps GHP2 Series Ordering Code Shaft* ... Seals omit (T range = -10°C + 80°C) V H Options T KA OR*** ... E2 = external drain 9/16-18 UNF*** Drain E4 = external drain 7/16-20 UNF*** E1 = external drain G1/4 E3 = external drain G3/8 only for VM options (only for KA ports) (*) = to be specified if different from standard “pump type”. (**) = only for R rotation. (***) = Drain ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). E0 = internal drain (****) = Drain ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1) 24 6 9 10 12 13 16 20 22 25 30 34 37 40 BK4 BK2 BK7 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

Gear Pumps GHP2 Series Accessories supplied with the standard pump: woodruff key (code 522057), M12x1.5 hexagonal nut (code 523016), washer (code 523005). Standard ports: M6 threads depth 13 mm, M8 threads depth 17 mm. The tapered shaft is also available with 3,2 mm key ("T3"). 25 GHP2-D-12 8.3 11.8 280 295 310 3500 48.5 98 13 13 M8 40 GHP2-D-22 16.0 22.8 260 275 290 4000 54.5 110 19 13 M8 40 GHP2-D-20 14.1 20.1 260 275 290 4000 53 107 19 13 M8 40 Type Displacement Flow at Maximum Pressure Maximum Dimensions 3 cm /rev litres/mim bar bar bar rpm mm mm mm mm mm GHP2-D-6 4.5 6.4 280 295 310 4000 45.5 92 13 13 M6 30 GHP2-D-9 6.4 9.1 280 295 310 4000 47 95 13 13 M6 30 GHP2-D-10 7.0 10.0 280 295 310 4000 47.5 96 13 13 M8 40 1500 rev/min P P P Speed L M d D h H 1 2 3 GHP2-D-13 9.6 13.7 280 295 310 3000 49.5 100 13 13 M8 40 GHP2-D-16 11.5 16.4 280 295 310 4000 51 103 19 13 M8 40 GHP2-D-25 17.9 25.5 260 75 290 3600 56 113 19 13 M8 40 GHP2-D-30 21.1 30.1 230 245 260 3200 58.5 118 19 19 M8 40 GHP2-D-34 23.7 33.7 230 245 260 3000 60.5 122 19 19 M8 40 GHP2-D-37 25.5 36.4 210 225 240 2800 62 125 19 19 M8 40 GHP2-D-40 28.2 40.1 200 215 230 2500 64 129 19 19 M8 40 GHP2-D-50 35.2 50.2 160 175 190 2500 69.5 140 21 19 M8 40 OUTLET INLET www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

Gear Pumps GHP2A Series Inlet and outlet standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). Accessories supplied with the standard pump: key (code 522067). Mounting flange 82-2 (A) in compliance with SAE J744c. 26 OUTLET INLET GHP2A-D-13 9.6 13.7 280 295 310 4000 49.5 100 ⁷⁄ -14 UNF 1¹⁄ -12 UNF Type Displacement Flow at Maximum Pressure Maximum Dimensions GHP2A-D-30 21.1 30.1 230 245 260 2200 58.5 118 ⁷⁄ -14UNF 1¹⁄ -12 UNF GHP2A-D-37 25.5 36.4 210 225 240 1800 62 125 ⁷⁄ -14 UNF 1¹⁄ -12 UNF 1500 rev/min P P P Speed L M d D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm GHP2A-D-6 4.5 6.4 280 295 310 4000 45.5 92 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-9 6.4 9.1 280 295 310 4000 47 95 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-10 7.0 10.0 280 295 310 4000 47.5 96 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-12 8.3 11.8 280 295 310 4000 48.5 98 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-16 11.5 16.4 280 295 310 4000 51 103 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-20 14.1 20.1 260 275 290 3200 53 107 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-22 16.0 22.8 260 275 290 2800 54.5 110 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-25 17.9 25.5 260 275 290 2500 56 113 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-34 23.7 33.7 230 245 260 2000 60.5 122 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A-D-50 35.2 50.2 160 175 190 1800 69.5 140 ⁷⁄ -14 UNF 1⁵⁄ -12 UNF GHP2A-D-40 28.2 40.1 200 215 230 1800 64 129 ⁷⁄ -14 UNF 1¹⁄ -12 UNF www.jbj.co.uk/gear-pumps.html #DriveLineHarmony

Gear Pumps GHP2A3 Series Inlet and outlet standard ports are machined in compliance with threaded port O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). Accessories supplied with the standard motor: key (code 522068). Mounting flange 101-2 (B) in compliance with SAE J744c. 27 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony OUTLET INLET 1500 rev/min P P P Speed L M d D I 2 3 GHP2A3-D-30 21.1 30.1 230 245 260 2200 77.5 137 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-6 4.5 6.4 280 295 310 4000 64.5 111 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-12 8.3 11.8 280 295 310 4000 67.5 117 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-50 35.2 50.2 160 175 190 1800 88.5 159 ⁷⁄ -14 UNF 1⁵⁄ -12 UNF GHP2A3-D-13 9.6 13.7 280 295 310 4000 68.5 119 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-40 28.2 40.1 200 215 230 1800 83 148 ⁷⁄ -14 UNF 1¹⁄ -12 UNF Type Displacement Flow at Maximum Pressure Maximum Dimensions 3 cm /rev litres/mim bar bar bar rpm mm mm GHP2A3-D-9 6.4 9.1 280 295 310 4000 66 114 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-34 23.7 33.7 230 245 260 2000 79.5 141 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-10 7.0 10.0 280 295 310 4000 66.5 115 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-20 14.1 20.1 260 275 290 3200 72 126 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-22 16.0 22.8 260 275 290 2800 73.5 129 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-25 17.9 25.5 260 275 290 2500 75 132 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-16 11.5 16.4 280 295 310 4000 70 122 ⁷⁄ -14 UNF 1¹⁄ -12 UNF GHP2A3-D-37 25.5 36.4 210 225 240 1800 81 144 ⁷⁄ -14 UNF 1¹⁄ -12 UNF

Gear Pumps GHP2BK1 Series Accessories supplied with the standard pump: woodruff key (code 522055). M12x1.5 exagonal nut (code 523016), washer (code 523005). Standard ports: M6 threads depth 13 mm. 28 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony GHP2BK1-D-25 17,9 25,5 260 275 290 4000 55,8 113 20 GHP2BK1-D-37 25,5 36,4 210 225 240 2600 61,8 125 20 Type Displacement Flow at Maximum Pressure Maximum Dimensions GHP2BK1-D-12 8,3 11,8 280 295 310 4000 48,3 98 15 1500 rev/min P P P Speed L M D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHP2BK1-D-9 6,4 9,1 280 295 310 4000 41 95 15 GHP2BK1-D-10 7,0 10,0 280 295 310 4000 47,3 96 15 GHP2BK1-D-16 11,5 16,4 280 295 310 4000 47,5 103 20 GHP2BK1-D-6 4,5 6,4 280 295 310 4000 39,8 92 15 GHP2BK1-D-13 9,6 13,7 280 295 310 4000 43,1 100 20 GHP2BK1-D-20 14,1 20,1 260 275 290 4000 47,5 107 20 GHP2BK1-D-22 16,0 22,8 260 275 290 4000 47,5 110 20 GHP2BK1-D-30 21,1 30,1 230 245 260 3400 47,5 118 20 GHP2BK1-D-34 23,7 33,7 230 245 260 3000 55 122 20 GHP2BK1-D-40 28,2 40,1 200 215 230 2600 63,8 129 20 OUTLET INLET

Gear Pumps GHP2BK2 Series To mount the pump: n.2 M10 screws with a torque wrench setting fixed at 46 ± 4 Nm. Accessories supplied with the standard pump: woodruff key (code 522055), M12x1.5 exagonal nut (code 523016), washer (code 523005). Standard ports: M6 threads depth 13 mm. 29 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony OUTLET INLET GHP2BK2-D-13 9,6 13,7 280 295 310 4000 40,3 97 20 GHP2BK2-D-9 6,4 9,1 280 295 310 4000 38,2 92 15 GHP2BK2-D-10 7,0 10,0 280 295 310 4000 44,5 93 15 GHP2BK2-D-34 23,7 33,7 230 245 260 3000 52,2 119 20 GHP2BK2-D-6 4,5 6,4 280 295 310 4000 37 89 15 GHP2BK2-D-40 28,2 40,1 200 215 230 2600 61 126 20 1500 rev/min P P P Speed L M D I 2 3 GHP2BK2-D-16 11,5 16,4 280 295 310 4000 44,7 100 20 GHP2BK2-D-20 14,1 20,1 260 275 290 4000 44,7 104 20 GHP2BK2-D-22 16,0 22,8 260 275 290 4000 44,7 107 20 GHP2BK2-D-12 8,3 11,8 280 295 310 4000 45,5 95 15 Type Displacement Flow at Maximum Pressure Maximum Dimensions GHP2BK2-D-25 17,9 25,5 260 275 290 4000 53 110 20 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHP2BK2-D-30 21,1 30,1 230 245 260 3400 44,7 115 20 GHP2BK2-D-37 25,5 36,4 210 225 240 2600 59 122 20

Gear Pumps GHP2BK4 Series Accessories supplied with the standard pump: woodruff key (code 522055), M12x1.5 exagonal nut (code 523016), washer (code 523005). Standard ports: M6 threads depth 13 mm. To mount the pump: n.2 M10 screws with a torque wrench setting fixed at 46 ± 4 Nm. 30 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony GHP2BK4-D-16 11,5 16,4 280 295 310 4000 44,7 100 20 GHP2BK4-D-6 4,5 6,4 280 295 310 4000 37 89 15 Type Displacement Flow at Maximum Pressure Maximum Dimensions GHP2BK4-D-9 6,4 9,1 280 295 310 4000 38,2 92 15 GHP2BK4-D-13 9,6 13,7 280 295 310 4000 40,3 97 20 GHP2BK4-D-40 28,2 40,1 200 215 230 2600 61 126 20 GHP2BK4-D-12 8,3 11,8 280 295 310 4000 45,5 95 15 GHP2BK4-D-22 16,0 22,8 260 275 290 4000 44,7 107 20 GHP2BK4-D-10 7,0 10,0 280 295 310 4000 44,5 93 15 GHP2BK4-D-34 23,7 33,7 230 245 260 3000 52,2 119 20 GHP2BK4-D-20 14,1 20,1 260 275 290 4000 44,7 104 20 GHP2BK4-D-25 17,9 25,5 260 275 290 4000 53 110 20 GHP2BK4-D-37 25,5 36,4 210 225 240 2600 59 122 20 1500 rev/min P P P Speed L M D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHP2BK4-D-30 21,1 30,1 230 245 260 3400 44,7 115 20 OUTLET INLET

Gear Pumps GHP2BK7 Series Standard ports: M6 threads depth 13 mm. To mount the pump: n.2 M10 screws with a torque wrench setting fixed at 46 ± 4 Nm. 31 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Type Displacement Flow at Maximum Pressure Maximum Dimensions 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHP2BK7-D-6 4.5 6.4 280 295 310 4000 37.3 89.5 15 GHP2BK7-D-9 6.4 9.1 280 295 310 4000 38.5 92.5 15 GHP2BK7-D-10 7.0 10.0 280 295 310 4000 44.8 93.5 15 GHP2BK7-D-12 8.3 11.8 280 295 310 4000 45.8 95.5 15 GHP2BK7-D-13 9.6 13.7 280 295 310 4000 40.6 97.5 20 GHP2BK7-D-16 11.5 16.4 280 295 310 4000 45 100.5 20 GHP2BK7-D-20 14.1 20.1 260 275 290 4000 45 104.5 20 GHP2BK7-D-22 16.0 22.8 260 275 290 4000 45 107.5 20 GHP2BK7-D-25 17.9 25.5 260 275 290 4000 53.5 110.5 20 1500 rev/min P P P Speed L M D I 2 3 GHP2BK7-D-30 21.1 30.1 230 245 260 3400 45 115.5 20 GHP2BK7-D-40 28.2 40.1 200 215 230 2600 61.3 126.5 20 GHP2BK7-D-37 25.5 36.4 210 225 240 2600 59.3 122.5 20 GHP2BK7-D-34 23.7 33.7 230 245 260 3000 52.5 119.5 20 OUTLET INLET

T0 C0 S0 A C1 S1 C2 S2 A3 C3 S5 Max Torque 200 Nm Max Torque 135 Nm Max Torque 140 Nm Max Torque 185 Nm Max Torque 160 Nm Max Torque 200 Nm Max Torque 140 Nm Max Torque 140 Nm Max Torque 140 Nm Flanges Shafts Gear Pumps Flanges & Shafts GHP2 Series 32 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony jbj's in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. www.jbj.co.uk/hydraulicadaptors.html A collection of different ways of connecting hydraulic pumps and motors to various driver devices. A r a n g e o f c o m p o s i t e bellhousings to accommodate electric motor flanges from 300 mm d i ame t e r t o 800 mm diameter. See pages 40 to 44 of the Pump Drive Components t e c h n i c a l s p e c i fi c a t i o n catalogue. The package consists of a bellhousing and flexible drive coupling that are fully machined to suit the pump and any driving interface; diesel or petrol engine, electric or hydraulic motor. allow close coupling of hydraulic pumps directly to the flywheel / flywheel housing of diesel engines, electric and hydraulic motors.

Flanges Shafts Gear Pumps Flanges & Shafts GHP2 Series 33 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony T1 S3 BK1 BK2 T2 S4 BK4 T2 S4 BK7 G0 Max Torque 180 Nm Max Torque 140 Nm Max Torque 180 Nm Max Torque 140 Nm Max Torque 180 Nm Max Torque 140 Nm Max Torque 100 Nm jbj's in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. A r a n g e o f c o m p o s i t e bellhousings to accommodate electric motor flanges from 300 mm d i ame t e r t o 800 mm diameter. See pages 40 to 44 of the Pump Drive Components t e c h n i c a l s p e c i fi c a t i o n catalogue. A collection of different ways of connecting hydraulic pumps and motors to various driver devices. www.jbj.co.uk/hydraulicadaptors.html The package consists of a bellhousing and flexible drive coupling that are fully machined to suit the pump and any driving interface; diesel or petrol engine, electric or hydraulic motor. allow close coupling of hydraulic pumps directly to the flywheel / flywheel housing of diesel engines, electric and hydraulic motors.
