Elpex highly flexible couplings available from jbj Techniques Limited

www.jbj.co.uk/couplings.html#flender 31 #DriveLineHarmony ELPEX Series Introduction Highly Flexible Couplings The flexible rings are mounted without backlash and give the coupling progressive torsional stiffness, i.e. torsional stiffness increases in proportion to coupling load. Outer flanges with different connection dimensions are available for the type EFG. Examples of applications are mill drives in the cement industry, marine main and secondary drives or drives on large excavators powered by an electric motor or diesel engine. If the flexible rings are irreparably damaged or worn, themetal parts can rotate freely against one another, they are not in contact with one another. The flexible rings are fastened to the hub with a clamping ring and to the outer flange with a clamping ring, using pins and bolts. The split flexible rings can be changed without having tomove the coupledmachines. The ELPEX coupling is especially suitable for reversing operation or operation with changing directions of load. The ELPEX coupling is available in 9 sizes with a nominal torque of between 1600 Nm and 90000 Nm. The coupling is suitable for ambient temperatures of between -40 °C and +80 °C. Application Application-related types can be implemented on request. ELPEX couplings are highly torsionally flexible and free of torsional backlash. Because of their low torsional stiffness and damping capacity, ELPEX couplings are especially suitable for coupling machines with a very non uniform torque pattern. ELPEX couplings are also suitable for connecting machines with high shaft misalignment. Benefits Standard ELPEX coupling types are designed as shaft-shaft connections or flange-shaft connections. The ELPEX coupling is suitable for horizontal and vertical mounting positions or mounting at any required angle. The coupling parts can be arranged as required on the shafts to be connected. The coupling is delivered preassembled. The flexible rings are completely assembled. On the type ENG, the coupling halves have to be bolted together after the hub has beenmounted. On the type EFG, after mounting the coupling hub, only the outer flange has to be connected to themachine. The ELPEX coupling is frequently used for high-quality drives which have to guarantee very long service life in harsh operating conditions. Design &Configurations The ELPEX coupling's transmission characteristic is determined essentially by the flexible rings. The flexible rings are manufactured from a natural rubber mixture with amultiply fabric lining. The flexible rings are split so that they can be changed without having tomove the coupledmachines. On the EFG type, the outer flange is designed with connection dimensions for connection to e.g. a diesel engine flywheel. On ENG types, the outer flange is fitted to a second hub part, which then enables the shaft-shaft connection.
