PC, PCX, PCXV Series Screw Pumps (API 676) 04 10 Quality Products for Mechanical & Fluid Power

API 676 Compliant Screw Pumps PCX and PCXV Series Contents The details contained within this catalogue are reproduced in accordance with the latest information at going to press................ E & OE Page Main characteristics ........................................................................................................................................................................................................................................................................................................................................... 1 - 2 PCX series pump .................................................................................................................................................................................................................................................................................................................................................... 3 - 6 PCXV series pump ............................................................................................................................................................................................................................................................................................................................................... 7 - 10 PCX and PCXV series performance data charts ........................................................................................................................................................................................................................................ 11 - 18 Other oil and gas industry sector products ............................................................................................................................................................................................................................................................. 19 - 20 quality products for mechanical & fluid power

Description PCX and PCXV Series pumps for low/medium pressure lubrication circuits, API 676 compliant. Main features: Standard pump with steel outer casing. Porting to ANSI standards and available with radial or axial inlet. Standard materials from worldwide manufacturers ensure readily available supply. Versions for high viscosity, low noise and entrapped air. Foot mounted versions available as standard. Self priming. Extremely low pulsation. ATEX certificated on request. Full assemblies with motor and baseplate and spacer coupling available. API 676 Compliant Screw Pumps PCX and PCXV Series 1

INSTALLATION DATA Area Indoor or outdoor. Environment Industrial, marine. Ambient temp. Min./max. -25°C (storage only) / 0 to 60°C (operating) for different values contact jbj Techniques Limited. OPERATING DATA Fluid specification Hydraulic and lubrication oils. Suggested inlet strainer filtration 400 μ for sizes up 072, 800 μ for 083 and bigger sizes. Viscosity range 10 to 1500 cSt. Pump speed 750 to 3600 rpm. Rotation (viewed from coupling end) Clock wise (Standard version); counter clock wise on demand. TECHNICAL CHARACTERISTICS Design code API 676 latest edition. Delivery flow 10 to 5400 Ipm. Suction Pressure /max MIN: as per NPSH chart on page 18 / MAX: 10 bar for different values contact jbj Techniques Limited. Delivery pressure Up to 30 bar ≤ size 072 / UP to 20 bar ≥ size 083. Operating temperature range 0 to 70°C; 120°C max for different values contact jbj Techniques Limited. Casing design / hydrotest press. Standard 16 bar / 24 bar for different values contact jbj Techniques Limited. Seal Mechanical seal – API code USPFN for different values contact jbj Techniques Limited. Bearing type Radial ball on main driveshaft. Bearing lubrication By pumped fluid. Driver type AC voltage electric motor or Steam turbine for main and auxiliary service, DC voltage electric motor for emergency service. Driver shape PCX > horizontal on foot IM1001 (B3) or direct coupled to secondary shaft. PCXV > vertical flanged IM3011 (V1). Inlet & Outlet Connection Standard ANSI 150 B16.5 for different values contact jbj Techniques Limited. Pressure relief valve Integrated pressure relief valve available on request (internal or external recirculation). Concessionn to chapter 3.4 on API676 required. MATERIALS Casing/Flanges Carbon Steel or Stainless Steel for different values contact jbj Techniques Limited. Screws Nitrided Steel. Liner Cast Iron GG25 or Carbon Steel. O-rings Viton ®. Surface protection Sand Blasting SA 2,5 + Inorganic Primer 75μ; Finish painting to customer request. ATEX APPROVAL FOR USE IN EXPLOSIVE ATMOSPHERES API 676 Compliant Screw Pumps PCX and PCXV Series 2

Pump Components Pos Quantity Description 1 2 Socket head screw 2 8 Socket head screw 3 1 Pump casing 4 1 Shaft 5 1 Inspection flange 6 1 Mechanical seal 7 1 Motor flange 8 1 Retaining circlip 9 1 Radial ball bearing 10 1 Pump feet 11 1 O-ring 12 2 O-ring 13 8 O-ring 14 1 Discharge flange (standard) 15 1 liner 16 1 Suction flange (standard) 17 1 O-ring 18 1 Suction flange (optional) 19 1 Satellite spindle 20 1 Check valve 21 1 Driving screw API 676 Compliant Screw Pumps PCX Series Internal Detail 3

All dimensions in mm unless otherwise stated. See page 6 for available IN/OUT ports position API 676 Compliant Screw Pumps PCX Dimensions 4 For hydraulic oils, lubricating oils Admissible delivery pressure (continuous)= 30 bar at 2900 rpm and 1450 rpm

API 676 Compliant Screw Pumps PCX Accessories 5 Main characteristics: 1) Pump PCX series. 2) AC/DC voltage Electric motor or steam turbine. 3) Flexible coupling with distance between shaft ends (DBSE) min. 127 mm (5 inches). 4) Non sparkling coupling guard, steel or brass. 5) Baseplate according to API 676 rules. 2D or 3D dimensional drawings, available on request.

API 676 Compliant Screw Pumps PCX In/Out Connections 6

API 676 Compliant Screw Pumps PCXV Series Internal Detail 7 Pump Components Pos Quantity Description 1 2 Socket head screw 2 8 Socket head screw 3 1 Pump casing 4 1 Driven screws 5 1 Inspection flange 6 1 Mechanical seal 7 1 Motor flange 8 1 Retaining circlip 9 1 Radial ball bearing 10 1 O-ring 11 1 O-ring 12 1 O-ring 13 1 Discharge flange (standard) 14 1 liner 15 1 Suction flange (standard) 16 1 O-ring 17 1 Drive shaft 18 1 Check valve 20 1 Filling plug 21 4 Lifting eye

All dimensions in mm unless otherwise stated. Refer to page 10 for available IN/OUT ports position API 676 Compliant Screw Pumps PCXV Dimensions 8 For hydraulic oils, lubricating oils Admissible delivery pressure (continuous)= 30 bar at 2900 rpm and 1450 rpm

API 676 Compliant Screw Pumps PCXV Accessories 9 Main characteristics: 1) Pump PCXV series with top plate. 2) AC/DC voltage electric motor. 3) Flexible coupling with or without spacer. 4) Bell-housing in carbon steel or stainless steel. 5) Stainless steel suction strainer height adjusted to suit application. For each job we can supply dedicated 2D or 3D dimensional drawing, to customer requirements.

API 676 Compliant Screw Pumps PCXV Accessories 10

API 676 Compliant Screw Pumps PCX/PCXV Performance Charts 11 50 Hz Pressure limits apply as per each series characteristics as well as by other operating conditions 040 # 4C 040 # 4B 040 # 4A 032 # 4B 032 # 4A 029 # 4B 029 # 4A 025 # 6C 025 # 6B 025 # 6A 57,69 cc/rev 49,03 cc/rev 40,38 cc/rev 29,58 cc/rev 22,15 cc/rev 18,95 cc/rev 15,92 cc/rev 14,08 cc/rev 11,83 cc/rev 9,58 cc/rev

API 676 Compliant Screw Pumps PCX/PCXV Performance Charts 12 50 Hz Pressure limits apply as per each series characteristics as well as by other operating conditions 072 # 4C 072 # 4B 072 # 4A 060 # 4B 060 # 4A 055 # 4B 055 # 4C 055 # 4A 045 # 4B 045 # 4A 336,43 cc/rev 280,36 cc/rev 233,63 cc/rev 194,69 cc/rev 165,49 cc/rev 139,06 cc/rev 117,24 cc/rev 98,16 cc/rev 82,14 cc/rev 69,36 cc/rev

API 676 Compliant Screw Pumps PCX/PCXV Performance Charts 13 50 Hz Pressure limits apply as per each series characteristics as well as by other operating conditions 156#3A 156#3B 156#3A 126#3C 126#3B 126#3A 102#3C 102#3B 102#3A 083#3B 083#3A 3421,90 cc/rev 2807,71 cc/rev 2281,27 cc/rev 1831,66 cc/rev 1488,22 cc/rev 1202,03 cc/rev 195,27 cc/rev 787,72 cc/rev 637,68 cc/rev 527,80 cc/rev 434,66 cc/rev

API 676 Compliant Screw Pumps PCX/PCXV Performance Charts 14 60 Hz Pressure limits apply as per each series characteristics as well as by other operating conditions 040#4C 040#4B 040#4A 032#4B 032#4A 029#4B 029#4A 025#6C 025#6B 025#6A 57,69 cc/rev 49,03 cc/rev 40,38 cc/rev 29,53 cc/rev 22,15 cc/rev 18,95 cc/rev 15,92 cc/rev 14,08 cc/rev 11,83 cc/rev 9,58 cc/rev

API 676 Compliant Screw Pumps PCX/PCXV Performance Charts 15 60 Hz Pressure limits apply as per each series characteristics as well as by other operating conditions 072#4C 072#4B 072#4A 060#4B 060#4A 055#4C 055#4B 055#4A 045#4B 045#4A 336,43 cc/rev 280,36 cc/rev 233,63 cc/rev 194,69 cc/rev 165,49 cc/rev 139,06 cc/rev 117,24 cc/rev 98,16 cc/rev 82,14 cc/rev 69,36 cc/rev

API 676 Compliant Screw Pumps PCX/PCXV Performance Charts 16 60 Hz Pressure limits apply as per each series characteristics as well as by other operating conditions 156#3C 156#3B 156#3A 126#3C 126#3B 126#3A 102#3C 102#3B 102#3A 083#3B 083#3A 3421,90 cc/rev 2807,71 cc/rev 2281,27 cc/rev 1831,66 cc/rev 1488,22 cc/rev 1202,03 cc/rev 972,27 cc/rev 787,72 cc/rev 637,68 cc/rev 527,80 cc/rev 434,66 cc/rev

API 676 Compliant Screw Pumps PCX/PCXV Information 17 The following table shows kinematic viscosity for standard ISO VG oils at given temperatures. Viscosity has to be considered not only when calculating power absorbed by the pump, but also to check self-priming capability (also related to driving speed and intrinsically dependent on pump size). Figures stated are subject to variations, due to other factors i.e. oil additives or when oils are developed for specific application, due to this figures in this table are for example only.

API 676 Compliant Screw Pumps PCX/PCXV Information 18 NPSH is an acronym for Net Positive Suction Head It indicates the pressure required by the pump in order to provide suction without cavitation. It is opportune that a margin of a meter of liquid column is provided between NPSH available in the system and the NPSH required by the pump.

API 676 Compliant Screw Pumps Other Oil & Gas Industry Products 19 PZ Series Delivery flow 400 to 5400 LPM ( 105 to 1425 USGPM) Admissible delivery pressure up to 16 bar (232 psi)* Admissible suction pressure –0,5 to 10 bar ( –7,3 to 145 psi)* Kinematics viscosity 10 to 400 cSt STD* Admissible temperature 0 to 120 °C (32 to 248 °F) Driving speed 1500 to 1800 rpm for other version max. 3000 rpm Average noise level 65 ÷ 75 dB(A) at 1800 rpm according to pump dimension Recommended filtration 60 micron max, (not abrasive contaminant) ISO4406 19 / 16 – NAS 10 Direction of rotation Clockwise, as seen from the driving side *For different values contact jbj Techniques Limited technical office, telephone: 01737 767493 or email: info@jbj.co.uk * Reduced pressure limits apply dependent on fluid viscosity and driving speed. Consult the performance charts for the individual pump size. For different functional characteristics, please contact our technical office. PX Series Delivery flow 10 to 3000 LPM ( 2,6 to 800 USGPM) Admissible delivery pressure up to 30 bar (435 psi) continuous* Admissible suction pressure –0,5 to 10 bar ( –7,3 to 145 psi)* Kinematics viscosity 10 to 400 cSt* Admissible temperature 0 to 120 °C (32 to 248 °F)* Driving speed 750 to 3600 rpm Average noise level 53 ÷ 68 dB(A) at 2900 rpm according to pump dimension Recommended filtration 60 micron max, suction side (not abrasive contaminant) ISO4406 19 / 16 – NAS 10 Direction of rotation Clockwise, as seen from the driving side * For different values contact jbj Techniques Limited technical office, telephone: 01737 767493 or email: info@jbj.co.uk * Standard valve setting mod. B: 7 – 16 bar (102 – 232 psi). Reduced pressure limits apply dependent on fluid viscosity and driving speed. Consult the performance charts for the individual pump size. For different functional characteristics, please contact our technical office. MPVA Series Flow Meter Delivery flow 0,9 to 900 LPM approx ( 0,24 to 240 USGPM)* Admissible delivery pressure 350 bar continuous (base version 200 bar) Admissible suction pressure –15 to +70 °C* Viscosity 1 ÷ 5,000 cSt Admissible temperature 0 to 120 °C (32 to 248 °F)* Types of fluid lubricant oils and chemically neutral mixes, even with low lubricating power** Recommended degree of filtration NAS 10 ÷ 12 Precision class 0,2% (0,4% on range 30 - 1) Standard construction material aluminium body* Type of O/P square wave signal in frequency, direct function of flow rate * For different values contact jbj Techniques Limited technical office, telephone: 01737 767493 or email: info@jbj.co.uk Special versions are available for specific applications (flow rates, temperatures and non-standard materials, bi-directional flow reading) as well as customised versions.

API 676 Compliant Screw Pumps Other Oil & Gas Industry Products 20 VMPI Series Pressure Relief Valve Delivery flow 400 to 5400 LPM ( 105 to 1425 USGPM) Max pressure* see dimensional chart* Admissible suction pressure –0,5 to 10 bar ( –7,3 to 145 psi)* Kinematics viscosity 10 to 400 cSt* Admissible temperature 0 to 100 °C (32 to 212 °F)* Recommended filtration 60 micron max, (non-abrasive contaminant) ISO4406 19 / 16 – NAS 10 *For different values contact jbj Techniques Limited technical office, telephone: 01737 767493 or email: info@jbj.co.uk * Reduced pressure limits apply due to fluid viscosity and driving speed. Consult the performance charts for the individual pump size. For different functional characteristics, please contact our technical office.
